Wld9300 and Wld-PS-B3 (CE) Spray Booth and Preparation Station

Wld9300 and Wld-PS-B3 (CE) Spray Booth and Preparation Station
Price: US $ 72000-75000/Piece
Trade Terms: FOB,CFR,EXW
Min Order: 1/Piece
Pay Type: L/C,T/T,Western Union
Prod Model: WLD9300 and WLD-PS-B3
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
External Size: 7X5.45X4m
Internal Size: 6.9X3.9X2.8m
Main Door Size: 3X2.75m
Air Flow: 30000m³/H
Air Speed: 0.3-0.5m/S
Fuel Consumption: 5-6kg/Vehicle
Total Power: 27kw
Vehicle Suited: Saloon Car/Jeep
Certification: CE
Airflow Direction: Fully Undershot-type
Heating Mode: Diesel
Paint Mist Treatment: Dry-type
Condition: New
Type: Auto Spray Baking Booth
Substrate: EPS or Rock Wool
Brand: Weilongda

Product Description

WeiLongDa Spray booth
WLD9300 (CE) Luxury Car Spray Booth Specifications:

External Size7000×5450×4000Front Door3000(W)×2750(H)mm
Aluminum Frame
Internal Size6900×3900×2800Total Power         27KW
Cabin SystemWallboardFire-retardant composite molding Sandwich style EPS
(epispastics polystyrene) (Rock wool and PU are optional )50mm thickness, EPS foam Density is 14kg/m³ ; The Colorful steel skin boards have been HDG(hot dip galvanizing),service life can reach 20 years without rusting. It keeps high insulation performance. Four colors for your choice, including blue, red, orange and white. High quality galvanized steel roof panel.
Basement300mm high powder coated galvanized steel sheet and square steel pipe construction. 3 row of checked plate and 2 row of grids, antirust and strong. The bearing capacity of driving grids up to 1000 kg per wheel; Basement frame is assembly formed by antirust steel square tube, the overall performance is good and strong. Powder coated full ramps.
Door3 pieces of luxury front doors, made of 0.8mm galvanized powder coated sheet, beautiful and strong. Size: 3000(W)×2750(H). 1 piece of emergency door.
Air Circulation SystemIntake Fan1×11KW direct drive turbo fan, air flow is 30000m³/h. BELIMO 20N electric damper. The wire core of our fans is full cooper so our fans are very durable.
Exhaust Fan1×7.5KW direct drive turbo fan, air Flow is 25000m³/h.
Air PipeMade of Galvanized steel sheet consisted of 4 pieces of straight pipe750×750×1000, and 1piece of elbow.
Nozzles60 units ceiling nozzles with 3 sets of centrifugal fan.3×2.2KW, special for water based paint spraying and drying.
Air circulation typeFull inner air circulation type, particularly rapid heating, insulation ability, especially energy; reflect its superior performance in a code environment.
FilteringMultilayer filtering structure. The primary pocket filter can capture granules larger than10μm. Ceiling filter capture granules bigger than 5μm. The floor filter and active carbon filter beside exhaust fan can capture paint and dust emission when painting. The air cleanliness in the working environment can reach 98%.
Heating SystemBurnerOriginal Italy RIELLO RG5S diesel burner, 260000Kcal/h. The heating time 4-5min (20-60ºC) Max temperature at 80ºC. Fuel consumption is 4-5kg/ vehicle.
Heat ExchangerTwo layers. Made of stainless steel. The heat exchange rate can reach 85%. Two layers to make our heating system safer and get higher heat exchange rate. What is more, we make two wings to make the temperature rise more quickly and save energy.
Heat Recycle   SystemAre recuperative, moisture is not recovered. The heat passes through thin plates, with recovery levels of up to 38%. The air streams are strictly separated, whenever solvents are used, the intake and exhaust streams have to be kept absolutely separate. That frequently makes the cross plate heat exchanger the perfect solution. The amortization period is short. Often less than two years.
Air make up cabinetThe surface plate is powder coated galvanized plate, antirust, strong and beautiful; The frame is treated by hot-dip, antirust and strong, more durable than ordinary surface treatment, more beautiful, nodes with no damage spot, rigidity.
Oil tank supportTank carefully made of high quality steel, the powder coated treatment, beautiful and durable.
Fume pipeFume pipe made of galvanized pipe, diameter of 190mm, 4 pieces of 1000mm long straight pipe, two 90 ° elbows.
LED Lighting SystemLight tubeCeiling light has 32 pieces of 16w LED lamps. Side light has 32 pieces of 16w LED lamps.1200 Lux. LED lamps are more bright and durable. The grade of lighting box's dustproof and waterproof reach IP54 grade.
Light boxWelded galvanized plate, powder coated treatment, surface brightness, color uniformity.
Filtering SystemPre-filterGrade G2 plate type fiber glass filter; Dual filtering structure. The pre-filter can capture granules larger than 10μm.
Ceiling filterEU5 grade high efficient filter; Ceiling filter capture granules bigger than 5μm.The air cleanliness in the working environment can reach 98%.
Floor filterMultilayer glass Fiber. The air cleanliness in the working environment can reach 98%.
Ceiling filter supportMade of tube steel frame, thickness of 1.2mm, epoxy powder coating, antirust and strong, rigid, beautiful and durable, can be repeated disassembly, not easy to damage, easy to replace filter cotton.
Pollution Control SystemSpecial configure with M pattern active carbon pocket filter system to filter paint and dust emission.
Control systemTouch Screen ControlLuxury touch screen Microcomputer control system, the system is composed of PLC, Converter, Air pressure transducer and Snyder electronic components.   Automation Intelligent control which can save 25% energy than normal system. Especially with over-temperature and over-pressure alarm device. The electricity will be cut off once alarm devices alert. It makes our booth very safe.
DamperAir damper, efficient and durable.

Preparation Station WLD-PS-B3

External Size7000×3550×3480mm(L×W×H)
Internal Size6900×3550×2800mm(L×W×H)
Plenum Dimension6900×3450×400mm(L×W×H)
Basement300mm galvanized steel basement, full grilles made by flat bar and round steel then galvanized. 2 ramps, external setting, 2000×750mm(L×W), surface is powder coating
Room BodyBack side with 50mm EPS wall panels, the other 3 sides with PVC curtains
Lighting SystemCeiling lights 8units × 4pcs=32pcs 36W, 800Lux
Intake and Exhaust System5.5KW double intake centrifugal fan, air capacity:15500 m3/h. 5.5KW double intake for exhaust air
Filtering SystemPre-filter, high efficiency filter, exhaust fiberglass filter
Control SystemFan operation switch, lighting switch, emergency stop
Total Power11.5 KW
Generator SettingExhaust air from rear side, powder coating treatment
Setting StyleSuspending steel hook from roof of building or steel column supporting
