Name: Wld25000 Bus Truck Train Auto Paint Spray Booth
Brand: ibuyautoparts.com
SKU: 762322175
Availability: InStock
Rating: 4.7 (22 reviews)

Price:	US $ 35000-50000/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Truck / Bus / Train Paint Spray Booth

1.Our factory establish in 2000
2. Real Factory for Spray Booth
3. We have export booth over 72 countris

Technical Parameters
External Size(mm)	(L) 25150 x (W) 8850 x (H) 5600
Internal Size: (mm)	(L) 25000 x (W) 5000 x (H) 5000
Door Size: (mm)	(W) 4000 x (H) 5000x2 sets
Air Flow: (m3 /h)	31000 x 4
Air Speed: (m/s)	0.3-0.5
Operation Temperature	< 80 degree
Power: (kw)	70
Vehicle Suited:	Train
Configuration
Wall Panel	Side Wall Panel isSandwich style EPS (epispastics polystyrene) 75mm thickness. Colorful steel skin boards 0.476mm thickness. Galvanized steel roof panel. Roof Panel EPS (epispastics polystyrene) 50mm thickness. Colorful steel skin boards 0.476mm thickness.
Door	Main Door: 2 sets 4 pcs of front doors with special rigid frame. Size: 4000(w) x 4800(h). Emergency Door : 4 sets.
Air Intake System (4sets)	Each set consists of 1 set 11kw Siemens turbo direct drive intake fan.
Air Exhaust System (4set)	Each set consists of 1x7.5kw Siemens Turbo Direct Drive exhaust fan. Exhaust two sides of wallboar with 4 sets exhaust area with Multi-layer fiberglass filter and active carbon packet filter. Air Exhaust pipe is 4 pcs straight pipe and 1 pcs elbow per set system. Total 16 pieces straight pipe and 4 sets elbow.
Lighting System	Ceiling light has 32units x 3pcs of 58w Philips lamps. Side light has 36 unites x 2pcs of 58 w Philips lamps. Total 168 pcs of 58 W lamps. 750 Lux.
Air Purification	Dual filtering structure. The primary filter(EU-3) can capture granules larger than 10μm.Ceiling filter(EU-5) capture granules bigger than 5μm. The air cleanliness in the working environment can reaches 98%.Exhaust Fiber Glass filters( EU-2), Active Carbon Packet filters ( EU-3).
Control System	Component is from Chinese Famous brand .With Overload/short circuit protect system .Lights seperate control .With Timer , alam lights,main switch and so on .

Prod Model:	WLD25000
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Internal Size:	(L) 25000 X (W) 5000 X (H) 5000
External Size:	(L) 25150 X (W) 8850 X (H) 5600
Air Flow: (M3 /H):	31000 X 4
Air Speed: (M/S):	0.3-0.5
Certification:	CE
Airflow Direction:	Lateral Undershot-type
Heating Mode:	Diesel
Paint Mist Treatment:	Dry-type
Condition:	New
Substrate:	EPS or Rock Wool
Brand:	Weilongda

Guangzhou Weilongda Electromechanical Equipment Co., Ltd., which established in 2000, is one of the first and largest automobile care and maintenance equipments manufacturers and suppliers in China. It manufactures spray booths, preparation stations, auto lifts and supplies body repair systems, car wash machine, wheel alignments, tire changers, wheel balancers and other relevant garage equipment to the clients all over the world.

Quality First, Service Highest is the policy carried by all Weilongda members. Quality and safety control system is applied throughout the whole produce procedures, from design and the raw material purchasing to parts fabrication, from welding to painting, from the product's factory assembling to packing and loading. All the products are produced strictly according to ISO9001: 2008 systems and CE standards.

After years of investment and management, WEILONGDA is a famous brand now. It enjoys high reputations among domestic customers as well as clients from England, Ireland, Poland, Sweden, Russia, Nigeria, Ghana, South Africa, America, Australia, Japan and other Asian countries.

Please feel free to contact members of Weilongda and start a happy and win-win cooperation.

With your join, the future is better.
