Transformer Industrial Spray Booth (3D lift)

Name: Transformer Industrial Spray Booth (3D lift)
Brand: ibuyautoparts.com
SKU: 753820645
Availability: InStock
Rating: 4.7 (43 reviews)

Price:	US $ 55000-60000/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Transformer Industrial Open Roof Spray Booth

We have specialized in spray booth for over 15 years . Have Export over 72 countries . We can provide OEM service .

External Size:(mm)

9500x5650x7600

Front Door:(mm)

Aluminum Frame

4000(w)x7000(h)

Internal Size:(mm)

8000x5500x7000

Total Power:(kw)

Cabin System	Wallboard	Sandwich style EPS (epispastics polystyrene) 75mm thickness, Colorful steel skin boards 0.476mm thickness .Galvanized steel roof panel.
	Door	4pieces of front doors with special rigid frame,2 pieces of small doors,each size:0.8m*2m.
Air Circulation System	Air Intake system(2sets)	2x4kw intake fan. Total 4 units of 4kw intake fan. Belino electrical damper.
	Air Exhaust system	1×7.5kw exhaust fan ,Total 2 units of 7.5kw exhaust fan Multi-layer fiberglass filter. Exhaust air from basement or two sides of wallboard
	Air Flow: 24000×4m³/h. Air Speed: 0.3-0.5m/s.
Air Purification System	Dual filtering structure. The primary filter can capture granules larger than 10μm. Ceiling filter capture granules bigger than 5μm. The air cleanliness in the working environment can reaches 98%.
Lighting System	Ceiling light has 10units×3pieces of 36w lamps .Side light has 24units×2pieces of 36w lamps .Total 116pieces of 36w lamps.900 Lux.
3D lift	Two side with 3D lifts
Top opening	L6m*W1.5m

Prod Model:	WLD-TR
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Internal Size:	8X5.5X7m
Open Roof Size:	6X1.5m
Certification:	CE
Airflow Direction:	Fully Undershot-type
Heating Mode:	Diesel
Paint Mist Treatment:	Dry-type
Condition:	New
Type:	Painting Booth
Brand:	Weilongda

Guangzhou Weilongda Electromechanical Equipment Co., Ltd., which established in 2000, is one of the first and largest automobile care and maintenance equipments manufacturers and suppliers in China. It manufactures spray booths, preparation stations, auto lifts and supplies body repair systems, car wash machine, wheel alignments, tire changers, wheel balancers and other relevant garage equipment to the clients all over the world.

Quality First, Service Highest is the policy carried by all Weilongda members. Quality and safety control system is applied throughout the whole produce procedures, from design and the raw material purchasing to parts fabrication, from welding to painting, from the product's factory assembling to packing and loading. All the products are produced strictly according to ISO9001: 2008 systems and CE standards.

After years of investment and management, WEILONGDA is a famous brand now. It enjoys high reputations among domestic customers as well as clients from England, Ireland, Poland, Sweden, Russia, Nigeria, Ghana, South Africa, America, Australia, Japan and other Asian countries.

Please feel free to contact members of Weilongda and start a happy and win-win cooperation.

With your join, the future is better.
