| Inside Dimension | 6850×3850×2650 mm(L×W×H) |
| Outside Dimension | 7000x5400x3300mm(LxWxH) |
| Front Door | 3000×2600 mm(W×H), 3 folds |
| Service Door | 750×1800mm(W×H), 1 unit |
| Basement | Galvanized steel, 300mm high, 2 rows of grilles and 3 rows of diamond plate; 3pcs front and 2pcs side ramps, 1pc stair. |
| Wall Panel | 75mm thick rock wool panel with double 0.476 steels, width: 950mm, tongue and groove interlock structure. |
| Intake&Exhaust System | Inlet: 1×11KW centrifugal fan, air capacity: 22000m3/h.
Outlet: 1×11KW centrifugal fan, air capacity is 22000m3/h. |
| Lighting System | Ceiling Lights: 8units×4pcs=32pcs×36W, with electronic ballasts, illumination≥800Lux.
Side Lights: 10units×2pcs=20pcs ×30W. |
| Heating System | Germany BALTUR26 diesel burner, 260000Kcal/h. Stainless steel heat exchanger, equipped with ventilation pressure controller, Pneumatic damper. |
| Purification System | Pre-filter, ceiling filter, fiberglass filter, activated carbon filter |
| Controlling System | PLC digital controlling, temperature and time setting switch, spray & baking switch, light switch, temperature display, humidity display, emergency stop, breakdown alarm, accumulative time, etc. |
| Total Power | 24 KW |
Car painting, Automobile Baking, Portable Auto Spray Booths
1. Italian Riello RG5S diesel burner
2. SUS304 Stainless steel heat exchanger
3. Anti-flame and Heat-Insulation
Turbo Fan Electrical Heat Downdraft Auto Spray Booths For Automobile Painting, Maintenance
1) For car painting and baking
2) maintains a high level of safety and performance together with top quality construction and materials
3) Various systems of environmental protection are optional for customers
4) A wide range of colors available: White, red, marine blue, gray, orange
5) Trustworthy durability of each parts
6) Good after-sales service
Packaging & Delivery
Packaging Detail: Export professional packages. Our packages are professional. We use the iron bracket package and it can fix the products and prevent them from broken. Moreover, we will label every components and it is easy for the customers to distinguish
Delivery Detail: To effect shipment within 7 days after deposit
Qingdao Hua Yushun Commercial Co., Ltd belongs to Captain Auto Equipment Group, which is responsible for exporting for all the products of Captain Group. And Captain is a professional designer and manufacturer of mechanical equipment, which is developed from SK spray booth built in 1992. Captain developed day by day, and established Shandong painting production base and sandwich panel production base. Now it can produce painting equipments more than 3000 sets, about 2, 000, 000 square meters different kinds of sandwich panels, and various kinds of steel ducting 800, 000 meters one year. Also Captain established Zhucheng sandblasting production base in 2002, and injection pieces production base in 2005. And in 2006, Captain established Qingdao Commercial Center, which is operated by Qingdao Hua Yushun Commercial Co., Ltd who is responsible for all the global importing and exporting business. Formed a good industry pattern that is the sells presses to production, and production streghten sales.
· Now the products of Captain group refer to auto repair quipments, furniture spray booth, preparation bay, shot blasting machine, antiseptic treatment production line, injection pieces, all kinds of EPS panel, rock wool panel, glass fiber panel and decorative panel outside, commercial kitchen equipment, etc.
· After all these years, high-quality products and good service won wide reputation for our group from our buyers, and our products are exported to Germany, the United States, Sweden, the Netherlands, Denmark, Romania, South Africa, Australia, Canada, Italy, New Zealand, Nigeria, Zambia, Thailand, Chile and other countries and regions.
Face to the ever-changing market, Captain looks providing more secure, reliable, energy conservation and environmental protection products as it's responsibility, listens to the buyer's comments carefully, improve the quality of products and service, Continue to increase the research and development ability of enterprise innovation and equipment; We will paste with the future, and slipped through the waves.
