Feature:
A. Prep stations make it possible for users to prep and perform minor paint work in one area without moving the vehicle.
B. Prep stations speed up the drying process and improve the overall quality of your finished product.
C. Two airflow choice, above ground exhaust box and pit style downdraft, allow easy integration into new or existing body shop layouts.
D. Optional heat units are available for high production needs.
External Dimension(M) | 7.15X4.0X3.43 |
Internal Dimension(M) | 6.0X4.0X2.65 |
Intake Fan Capacity (m3/h) | 12000 |
Exhaust Fan Capacity (m3/h) | 12000 |
Speed(rpm) | 900 |
Pressure(Pa) | 800 |
Power (kw) | 9.5 |
Intake Fan(KW) | 1×4 |
Exhausted Fan(KW) | 1×4 |
Floor Filter | Italian Fibre Filter |
Roof Filter | Italian Filter |
Outlet Filter | Chinese Filter |
Filter Supporter | Steel made powder coating |
Control Panel | Chinese components |
Top Light Box | 8×3×36W |
Luminance(lux) | 800 |
Unit Casing | Steel made powder coating with sectional frame |
Noise(db) | ≤80db |
Left and Right Side | Remote control PVC roller blind |
Front | Remote control PVC roller blind |
Back Side | Sandwich style, g=50mm,polystyrene |
Roof | Galvanized steel plate |
Basement | 330mm integral basement with anti-rusted steel tube |
Grate | 2 rows of 5mm galvanized grate and 3 rows of steel plate |
Ramp | 3×600mm steel plate |
Ducting | 4m galvanized steel ducting, one 90° galvanized bend |
Required Voltage | 3 Phases 380V/50HZ |
Packing | Disassembly with carton |
Container Loads(set/40HQ) | 3 sets |
Standard Prep Stations optional
l Semi-Downdraft or Pit-Style Downdraft or Full Downdraft
l With or without overhead plenum
l With or without heater & intake system
l Free-standing with structural steel support or suspended from the shop ceiling
Optional
l Cupboards in the rear of Prep Stations to store painting materials and equipments
l Roll-Up Curtains(motorized controls/manual operation)
Other features
l Overspray and dust control by 95% filter efficiency
l PHILIPS lamps, BELIMO damper and RIELLO burner
l Main electric components are CE listed
l All hardware, fasteners, sealants
l 24 months warranty
l Delivery time of standard prep station can reach 10 business days
l Bubble film packaging for sea transportation in bulk, special steel tray packages are accepted
