Fuse Disconnector (HR) with Good Quality

Name: Fuse Disconnector (HR) with Good Quality
Brand: ibuyautoparts.com
SKU: 690075725
Availability: InStock
Rating: 4.4 (110 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB
Min Order:	10/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

1. HR17 fuse disconnector
2. Matched with NT and NH series fuse link
3. CE certificate
4. Rated voltage: 690V

HR17 fuse disconnector
Product Description
HR17 fuse switch/fuse isolator (CE)
1. Matched with NT and NH series fuse link
2. CE certificate
3. Rated voltage: 690V

4. Specification:

Fuse switch, fuse isolator, switch

IR17 fuse type isolation switch, rated insulating voltage AC800V. Rated operating voltaged 690V. 400V, rated frequency 50Hz. The rates current 160A~630A mainly used as power switch, isolating switch and emergency switch with function of protection in the circuit with high short circuit current and motor circuit, this switch is not used to operate the single motor.

This product is coformity with standard GB14048.3-2002. IEC 947-3(1999).

type	switch rating heat current(A)	pole no	assorted fuse	rated current(A)
IR17-160/30 IR18-160	160	3.4	NT00	4 6 10 16 20 25 32 35 40 50 63 80 100 125 160
IR17-250/30 IR18-250	250	3.4	NT1	80 100 125 160 200 224 250
IR17-400/30 IR18-400	400	3.4	NT2	125 160 200 224 250 300 315 355 400
IR17-630/30 IR18-630	630	3.4	NT3	315 355 400 425 500 630

Prod Model:	HR
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Operation:	Electric Type
Installation:	Fixed
Speed:	High-Speed Circuit Breaker
Arc-Extinguishing Medium:	Air
Function:	Ovp(Overvoltage Protection)
Certification:	Ce,CCC
Type:	Fuse

Founded in 1999, CEA Group International Co., Ltd.Is being acknowledged as one of the most respected nationwide manufacturers and exporters of low voltage electrical apparatus in P.R of China.

The Group, comprising 5 factories, owns a production area of 50, 000m2 and employs more than 1, 000 staff.During the past 13 years, we invested abundant resources in both research and development and employee training programs.The company was ranked in the front of 100 tops of wenzhou private enterprises." CEA" is named as a famous trademark in domestic and overseas markets.Our company has took the lead in applying IS09001 Quality Management System and ISO14001 Environmenttal Management System.Many products are certified under international certificate, such as CB, CE, BS, VDE, UL, SONCAP, CCC.

Currently, we have manufactured and exported more than 160 varieties of products, with over 2000 types of low voltage electrical apparatus including all kinds of LED lighting, Circuit Breakers, Contactors, Relays, Starters, Switches, , Wire & Cable and Electrical Accessories etc.As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching South East Asia, Middle East, South America, Africa, Europe.

We are fully aware of the fact that only "Versatile Staff, Distinctive Quality and Advanced Technology"enable us to survive and succeed in today's intensively competitive market.Hence, we will be with overall technology support, good service to meet the requirements of world.

Enquiries from both domestic and overseas customers are cordially welcomed.Just Tell Us Your Requirements and Let Us Do The Rest For You!
