| Outside Size(mm) | 7000x5350x3300 | Front Door(mm) | 3000x2600(WxH) |
| Inside Size(mm) | 6900x3900x2650 | Total Power | 45kw |
| Basement | δ=1.0mm galvanized steel for bottom coaming, the
floor beam is made of galvanized square tube
whose specification is 40mmx80mmx1.8mm; 3 rows
of diamond plate, 2 rows of grilles, made by 30mmx4mm
flat steel, then paint. δ=2.75mm diamond steel plate
to make 2 embossed steel ramp, 1 piece stairs. The
whole structure is strong, durable and beautiful. |
| Cabin System | 50mm EPS panel, double 0.376mm steel with tongue
and groove structure. The main door is without
aluminum side cover, produced by one-time suppress.
The watching window is with 5mm white glass.
Aluminum alloy hinge and extraposition bolt.
One fold person door, size is 1800mmx750mm,
with mechanical pressure lock and 5mm glass window. |
| Ventilation System | 2 sets 4kw YDW4.5L centrifugal fans for supplying,
air capacity is 26000m3/h; 1x5.5kw YDW5.6S
centrifugal fan for exhausting, air capacity is
15000m3/h. The frame is soldered by 50mmx50mm
square tube and with powder coating. The surface
sealing plate is made of δ=0.8mm galvanized steel
and with reinforcing ribs. |
| Ceiling | Air plenum chamber made by light-weight steel
structure, frame is soldered by 40mmx60mm
square tube; filter frame groove is bending with
δ=1.0mm galvanized steel with powder coating;
ceiling filter bracket is made of machining concave
steel pipe and ø6 round pipe with powder coating. |
| Lighting System | 4 tubes x 8 teams x 36w famous brand lights with
electric ballast, top lighting way installed with 45
degree angle, to ensure no double image and blind
area, illuminance>=1000Lux. 20pcsx30w side
lights in vertically embedded into the wall. The
protection glass is 5mm white glass. And the box is
bending by δ=0.8mm galvanized steel with powder coating. |
| Heating System | sliding short infrared lamps on both sides, total is 24kw;
Fixed short infrared lamps on the back, total is 6kw. |
| Purification System | Prefilter is using non-woven filter cotton; ceiling filter
is using CC-600G high effeicient filter, thickness 25mm,
flame retardant glass is F5. The floor filter is using
filter felt for paint mist.And M type active carbon for
the waste gas. |
| Electric Controlling System | High quality electronic elements, multi-protection for
the main circuit; temperature and time setting switch,
spray & baking switch, light switch, emergency
stop, breakdown alarm, etc. |
| FOB QINGDAO | USD 6300 |
Captain Spray Booth(Qingdao Hua Yushun Commercial Co., Ltd)
Is a professional leading factory in China, who is specializing in manufacture kinds of paint spray room system. And also offering full garage equipments, such as
Car care equipment.
Car spray&baking room system
Bus spray&baking room system
Furnitue spray&baking room system
Industrial painting&baking room system
High temperature baking room system
Customized spray&bake booth and Offer car spray baking booth accossories
Services We Supply
Customized service
More Than 90% Of Our Spraying Booth Is Customized.
1. We can design the machines according your requirements. At the same time, our engineers will give you our professional suggestions.
2. We can give you free technical support and consultation such as design your factory, make the factory layout drawing and so on.
After-sales service
1. Our fast and professional after service engineer team can go to your factory and install the machine, give you the operating guidance, and train your employees until they can operate the machine well.
2. We often ask feedback and offer help to our customer whose machine have been used in their factory for some time.
3. We provide 2 years warranty.
Captain Advantages*The same price higher quality, the same quality lower price! ! !
*2 years quality warranty! ! !
*Fast and stable supply capability! ! !
*Personalized design to meet customer various needs! ! !
Competitive Price and High Quality Spraying Booth with Perfect Service Is From Here.
Qingdao Hua Yushun Commercial Co., Ltd belongs to Captain Auto Equipment Group, which is responsible for exporting for all the products of Captain Group. And Captain is a professional designer and manufacturer of mechanical equipment, which is developed from SK spray booth built in 1992. Captain developed day by day, and established Shandong painting production base and sandwich panel production base. Now it can produce painting equipments more than 3000 sets, about 2, 000, 000 square meters different kinds of sandwich panels, and various kinds of steel ducting 800, 000 meters one year. Also Captain established Zhucheng sandblasting production base in 2002, and injection pieces production base in 2005. And in 2006, Captain established Qingdao Commercial Center, which is operated by Qingdao Hua Yushun Commercial Co., Ltd who is responsible for all the global importing and exporting business. Formed a good industry pattern that is the sells presses to production, and production streghten sales.
· Now the products of Captain group refer to auto repair quipments, furniture spray booth, preparation bay, shot blasting machine, antiseptic treatment production line, injection pieces, all kinds of EPS panel, rock wool panel, glass fiber panel and decorative panel outside, commercial kitchen equipment, etc.
· After all these years, high-quality products and good service won wide reputation for our group from our buyers, and our products are exported to Germany, the United States, Sweden, the Netherlands, Denmark, Romania, South Africa, Australia, Canada, Italy, New Zealand, Nigeria, Zambia, Thailand, Chile and other countries and regions.
Face to the ever-changing market, Captain looks providing more secure, reliable, energy conservation and environmental protection products as it's responsibility, listens to the buyer's comments carefully, improve the quality of products and service, Continue to increase the research and development ability of enterprise innovation and equipment; We will paste with the future, and slipped through the waves.
