Item No. PC-AS200 Specifications:1): Outside
dimension:7000×5560×3430mm (L×W×H); 2): Inside dimension: 6900×4000×2650mm (L×W×H)
3): Front door dimension:
3000×2600mm (W×H);
4): Working door dimension:
800×2000mm (W×H)
Cabin System:1): Wall
panel: 50mm thickness flame-resistant
and heat-preserving EPS panel; 0.426mm thickness double-face colored steel sheet
2): Roof panel: galvanized steel sheet
3): Basement:
height is
300mm; galvanized steel
sheet frame and square steel
duct support beam assembling,
3 rows embossed plates and 2 rows grilles4): Ramp: 2 partial ramps, single size is W600 x L2000 (mm), embossed plate structureLighting System:1): Ceiling
Lights: 8Groupsx4Pcs=32Pcs
x16W; LED lamp2): Illuminance: ≥600Lux3): Glass:
tempered4): Sealing: omnisealGenerator Structure:1): Upper damper; side
upper intake air;
rear upward
exhaust2): Quadrate steel
frame, powder coated3): Galvanized steel
sheet mask board,
powder coated,
with the acoustic
plate and heat preservation
plateAir Purification System:Primary
filter, High efficiency filter (ceiling
filter), Floor
Paint stop filter (fiber glass)
Air Circulation System:1): Air speed: 0.25m/s2): Air recycling times: 280times/h3): Specifications
Air intake system | Model: YDW-4.5AL1 |
Air exhaust system |
\ |
| Air capacity: 12500m3/h |
| Pressure: 822Pa |
| Rolling speed: 900rpm |
| Power: 4kw |
| Quantity: 2sets |
| Intake duct supply | Fresh air comes in directly | Exhaust duct supply | 4m straight from the cabin and 1x90° elbow |
| Painting & baking exchange | 10N electric actuator, damper adjustment to exchange |
Heat System:1): Heat exchanger: stainless steel
SUS304, argon arc welding, 2-layer heat exchanging sheets 2): Italy Riello G20 diesel burner, max heating capacity: 180000kcal/h3): Oil consumption 4~6L/set; Heating time 5~7minutes (from 20° to 60°)4): Chimney: 4m from the cabin and 1x90° elbow, galvanized sheet madeControl System:1): Function button: paint, rising temperature paint, bake, temperature setting, time setting, lighting, hour meter, fan failure indicator light, burner failure indicator light
2): Protective device:
Emergency stop switch, breakdown alarm, thermal protector3): Start: direct4): Electric wire: 3 phases 5 lines
Total Power: 9KW
Voltage Require: 380V, 3P, 50HzCustom-made choices:As a professional manufacturer of paint booth for more than 15 years, Paintcolor has produced a large number of car paint booths,
bus paint booths, industrial spray booths, furniture spray booths, water fall spray booths, non-standard custom spray booths.
Paintcolor paint booth offers clients a wide range of paint booth that can fit a number of requirements.
For instance, the customized options and solutions could be mainly:
1. Customized dimensions (L, W, H)
2. Wall panels (EPS, Rockwool, PU)
3. Basement (with ramp, floor level, dig-pit)
4. Heating method (diesel, gas, electricity, infra-red, Electric heating tube, Electric radiator, steam, hot water)
5. Fan cabinet position (left, right, back, on roof)
6. Air circulation mode (full down draft, semi down draft, side draft, cross draft)
7. Power supply (380V/220V, 3P/1P, 50hz/60hz)
Paintcolor professional and efficient designing ability ensures the reliable performance of the booth even after years of use and brings our clients great returns on their investment.
Please contact us if you have custom-made choice. Paintcolor paint booth gives you a perfect solution!VISIT www.spraybooth-online.com TO FIND MORE!
