CE Certificated Car Spray Booth, Paint Unit, Paint Spray Booth
Price: |
US $ 4990-6990/Set |
Trade Terms: |
FOB,CFR,CIF |
Min Order: |
1/Set |
Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
Prod Model: |
CP-Y-B |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Outside Dimension: |
7050X5050X3500mm(Lxwxh) |
Inside Dimension: |
6900X3900X2800mm(Lxwxh) |
Main Door: |
3-Folds: 30002750mm (Wxh), Aluminium Alloy Door |
Personal Door: |
1-Fold: 8001900mm (Wxh),Aluminium Alloy Door Fram |
Wallboard: |
EPS Colorful Steel Skin Panel,75mm Thick,Steel 0.4 |
Basement & Floor: |
300mm Height, 2 Grills |
Lighting System: |
Ceiling: 8unitsx3, Side: 6unitsx3 |
Intake Fan: |
2X5.5kw |
Extract Fan: |
1X7.5kw |
Filtering System: |
600g High Efficiency Filter,Activated Carbon Filte |
Certification: |
CE |
Airflow Direction: |
Fully Undershot-type |
Heating Mode: |
Diesel |
Paint Mist Treatment: |
Dry-type |
Condition: |
New |
Brand: |
Captain |
Product Description
Competitive Price and High Quality Spraying Booth with Perfect Service Is From Here.
Items | Spec |
Outside Dimension | 7050×5050×3500mm(L×W×H) |
Inside Dimension | 6900×3900×2800mm(L×W×H) |
Main Door | 3-folds: 3000×2750mm (W×H), aluminium alloy door frame |
Personal Door | 1-fold: 800×1900mm (W×H),aluminium alloy door frame |
Wallboard | EPS colorful steel skin panel,75mm thick,steel 0.476mm thick,tongue groove style,compound construction,anti-flame and heat-insulation, aluminium roof panel. |
Basement & Floor | Complete steel assemble, height is 300mm, pave 3rows indented plates and 2rows grilles on the metal basement, 2Pcs ramps: 800×2000mm (W×L)/pc |
Lighting System | Ceiling Lights: 8Units×3Pcs=24Pcs×40W, with electronic ballasts,power-coated light box.Side Lights: 6Units×3Pcs=18Pcs×36W, with electronic ballasts, vertically set,power-coated light box. |
Generator Setting | Intake air from side back direction, quadrate steel frame, colourful coated steel plate |
Intake Fan | 2 sets of double-intake centrifugal fans for intake air, direct drive,5.5kw each,air capacity 30000m3/h in total. |
Extract Fan | 1 set of double-intake centrifugal fan for exhaust air, direct drive,7.5kw, air flow 20000m3/h in . |
Number Of Air Changes (times/hour) | 290 |
Wind Velocity At Full Load Inside The Room(M/S) | 0.3m/s |
Heating System | 1set Riello RG5S brand diesel oil burner, maximum heat productivity is 260,000Kcal/h, stainless steel heat exchanger, highest temperature is 80oC, electric damper executes from spraying to baking cycle . |
Maximum Working Temperature | 80 |
Heating Rate(/min 20--60) | 4-6 |
Filtering System | Pre-filter,600G high efficiency filter(ceiling filter),floor filter(fiberglass filter),activated carbon filter. |
Control Panel | Spraying, heat spraying, baking temperature, time setting, failure indicator, lighting switch |
Filter Efficiency | ≥98% |
Noise(db) | ≤75 |
Colour | Blue,red,white |
Total power(Kw) | 21KW |
