Vacuum suction: 180kg
Claw puller: Available
Vertical pull welding torch: Available
2. Feature:
Automatic mains voltage monitoring
Over-heat protection
Designed for dent pulling of different kinds of car steels such as coventional steel, stainless steel, ect.
Single-sided and double-sided welding
Various of welding prcedures are available such as shrinking, washer, direct-pulling, spot welding, flattening, waveform wire, stud welding, OT washer, triangle washer, etc
Complete with air filter and pressure regulator
Unique designed gun cable support arm allows flexible movement with 360 degree rotation
Triangle washer spot hammer for dent pulling
Digital graphic LCD display
Large pulling hammer and waveform wire for dent pulling
Stepless current regulation
10 preset weld programs
60 memory functions
3. Super Configuration:
Microprocessor contrl system optimizes the welding parameters, due to the adoption of advanced digital control technology and humanization design, all you have to do is select the welding current corresponding to the workpiece thickness to achieve the best weld quality
With DELIX, OMRON and Panasonic high-quality relay
Complete with triangle washers for dent pulling
High precision time adjustment system
The whole spot gun body is cast in polyamide
Sliding type pulling hammer
Equipped with switchable spot gun and multi-functional puller
Optional C-type gun and X-type gun is available
Stud welding is available
Adjustable welding current
Stepless current regulation
Complete with various of welding tools
Complete with pneumatic vacuum cupule
| Input voltage | AC380-440V 50/60Hz |
| Input power | 30KVA |
| Input current | 60A |
| Max Welding current | 13000A |
| One-side welding thickness | 1.0+1.5mm |
| Two-side welding thickness | 3.0+3.0mm |
| Cable lenth | 2500+2500, 2300+2300mm |
| Dimensions | 740x610x1800mm |
| Weight | 168kg |
