Name: Factory Produced High Pressure Low Price Rubber Hose, Hydraulic Rubber Hose
Brand: ibuyautoparts.com
SKU: 732931942
Availability: InStock
Rating: 4.6 (107 reviews)

Price:	US $ 0.85-1.21/Meter
Min Order:	4000/Meter
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

We also could offer the follow rubber hose:

Wire braid rubber hose:

1.SAE 100R1AT/DIN EN853 1SN

2.SAE 100R2AT/DIN EN853 2SN

3.EN857 1SC/2SC

4.SAE R16/R17

5.SAE 100R14/TEFLON HOSE

6.SAE R5

Wire spiral rubber hose:

1.DIN EN856 4SP

2.DIN EN856 4SH

3.SAE 100 R9

4.SAE 100 R12

5.SAE 100 R13

Fiber braid rubber hose:

1.SAE 100R7/EN855 R7

2.SAE 100R8/EN855 R8

3.SAE 100 R3

4.SAE 100 R6

Specifications
1. Top quality high pressure hose
2. Standard: SAE, DIN, JIS
3. Tube: Oil resistant synthetic rubber
4. Hydraulic hose, PTFE tube

Applications of premium brake hoses :
Designed for conveying air in truck and trailer brake systems.Truck and trailer manufacturers,aftermarket packagers and wholesaters use this hose.It is certified to meet SAEJ1402 requirements.

Construction of premium brake hoses :
Tube:excellent ozone resistant synthetic rubber
Reinforcement: high tensile braid of textiles
Cover: abrasion - and weather - resistant compounds
Temperature range: -40~ +212 F

Specifications of premium brake hoses :

Layers*Classics	Hose ID mm	Hose ODmm		Reinforcement diameter mm	Working pressure MPa	Minimum burst pressure MPa MPa	Minimum bend radius mm	Weight kg/m
1-5-21	5±0.5	12.7±0.8		9.5±0.6	21	63	90	0.25
1-6-21	6±0.5	16	+1.0	11.7±0.6	20	60	100	0.34
			-0.8
1-8-17.5	8±0.5	18	+1.0	13.7±0.6	17.5	52.5	115	0.42
			-0.8
1-10-16	10±0.5	20	+1.0	15.7±0.6	16	48	130	0.47
			-0.8
1-13-14	13±0.5	24	+1.2	19.7±0.8	14	42	180	0.64
			-0.8
1-16-12	16±0.5	27	+1.2	22.7±0.8	12	36	205	0.70
			-1.0
1-19-10	19±0.5	30	+1.2	25.7±0.8	10	30	240	0.84
			-1.0
1-22-9	22±0.5	33	+1.2	28.7±0.8	9	27	280	0.95
			-1.0
1-25-8	25±0.5	37	+1.2	32.2±0.8	8	24	300	1.09
			-1.0
1-32-6	32±0.7	44	+1.5	39.2±0.8	6	18	420	1.38
			-1.2
1-38-5	38±0.7	50	+1.5	45.2±0.8	5	15	500	1.80
			-1.2
1-51-4	51±1.0	63	+1.5	58.2±0.8	4	15	630	2.30

Product Test and Certification
The factory inspection:
100% Pressure Inspection
100% Throughput Inspection
100% Pass and Stop Inspection
100% Length,Surface Inspection
100% Internal Gassing clean

Prod Model:	GL180206004
Type:	Brake System
Material:	Rubber
Position:	Front
Certification:	DOT

Qingdao Folan Trade Co., Ltd was found in 2016. Since 2008, our factory are exported and supplied in the fitting of engine Parts. We have two foundries and 20-30 fully automatic CNC machining centers in order to meet our customer's production capacity.

Such as automotive coolant/fuel hose assembly, automotive air-condition hose assembly, automotive power steering hose assembly, automotive turbo charger hose assembly, automotive sunroof drain hose and automotive molding press hose assembly and other series over 2000 kinds of specifications. Its main customers are: FAW Volkswagen, DFCV, SAIC Volkswagen, Nissan(China), JAC group, Volkswagen AG, Italy FIAT, etc., integrated product market share up to 30%.
