4800/5800A Steel Body Single Side Spot Welder

Name: 4800/5800A Steel Body Single Side Spot Welder
Brand: ibuyautoparts.com
SKU: 699665525
Availability: InStock
Rating: 4.6 (31 reviews)

Price:	US $ 700-1000/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Set
Pay Type:	L/C,T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

The S-307/407 is integrated with functions of advanced washer welder, waved welding wire welder and spot welder in one.
1. Patent outlook, reasonable design, convenience for movement.
2. Changeable and multi-functinal welding torch and accessories.
3. Simple and practical panel from which it can easily set the current time.
4. Reminding operator of the equipment's status by temperature warming lamp and prolong the using life.
5. Current controlled by SCR with accurate stepless adjustment.

Model	S-307	S-407
Input voltage	1PH/220V, 50/60Hz	2PH/380V, 50/60Hz
Input power (KVA)	18	20
Input current (A)	18	23
Max. output current (A)	4800	5800
Single side welding thickness (mm)	0.6+0.8/0.8+1.0/1.0+1.2	0.6+0.8/0.8+1.0/1.0+1.2
Output voltage	Welding materials melting AC4-8V	Welding materials melting AC4-8V


Timer regulation range (S)	0.1-1.2 S (Stepless regulation)	0.1-1.2 S (Stepless regulation)
Current and voltage regulation	Stepless regulation	Stepless regulation
Size (mm)	615× 435× 990	615× 435× 990
Weight (Kg)	60	62

Prod Model:	S307 S407
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Steel Body Single Side Spot Welder:	6800A Spot Welder
Type:	Transmission Jacks
Certification:	GS
Update Method:	by Internet
