3/8 Inch Rubber Hose Oil Resistant Diesel Fuel Hose

Name: 3/8 Inch Rubber Hose Oil Resistant Diesel Fuel Hose
Brand: ibuyautoparts.com
SKU: 732932242
Availability: InStock
Rating: 4.4 (64 reviews)

Price:	US $ 0.55-2.51/Meter
Min Order:	500/Meter
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	GL013010
Fuel:	Gasoline
Body Material:	Alloy
Component:	Fuel Injection Device
Certification:	CCC
Stroke:	4 Stroke
Cylinder:	Multi-cylinder

Product Description

About Us

17+ years experience in rubber hose industry.
Main products: hydraulic hose, welding hose, oil hose, suction hose, etc.
Located in Qingdao,China, closed with the seaport
32 steel braiding machine, 2 sprial machine for 4 wire hoses, and 2 cotton braiding machine
Outstanding R&D engineers team.
OEM available.
Consistent and well trained team.
Experienced sales team for different markets.
ISO9001 approved production process

Factory manufacture high quality industrial rubber hose, low price rubber hose, hydraulic rubber hose

SAE 100R1AT rubber hose technical data:

Size		I.D		O.D	W.P		B.P		Min B.R	Weight	Length
mm	inch	Min	Max	Max	Mpa	Psi	Mpa	Psi	mm	Kg/m	m
5	3/16"	4.6	5.4	12.5	25	3625	100	14500	90	0.19	50-100
6.3	1/4"	6.2	7	14.1	22.5	3260	90	13050	100	0.21	50-100
8	5/16"	7.7	8.5	15.7	21.5	3120	85	12325	115	0.24	50-100
10	3/8"	9.3	10.1	18.1	18	2610	72	10440	130	0.33	50-100
12.5	1/2"	12.3	13.5	21.4	16	2320	64	9280	180	0.41	50-100
16	5/8"	15.5	16.7	24.5	13	1885	52	7540	200	0.45	50-100
19	3/4"	18.6	19.8	28.5	10.5	1520	42	6090	240	0.58	50-100
25	1"	25	26.4	36.6	8.8	1280	35	5075	300	0.88	50
31.5	1 1/4"	31.4	33	44.8	6.3	910	25	3625	420	1.23	20-40
38	1 1/2"	37.7	39.3	52.1	5	725	20	2900	500	1.51	20-40
51	2"	50.4	52	65.5	4	580	16	2320	630	1.97	20-40

Qingdao Folan Trade Co., Ltd was found in 2016. Since 2008, our factory are exported and supplied in the fitting of engine Parts. We have two foundries and 20-30 fully automatic CNC machining centers in order to meet our customer's production capacity.

Such as automotive coolant/fuel hose assembly, automotive air-condition hose assembly, automotive power steering hose assembly, automotive turbo charger hose assembly, automotive sunroof drain hose and automotive molding press hose assembly and other series over 2000 kinds of specifications. Its main customers are: FAW Volkswagen, DFCV, SAIC Volkswagen, Nissan(China), JAC group, Volkswagen AG, Italy FIAT, etc., integrated product market share up to 30%.
