Seaflo 220V 160psi Water Pump High Pressure for Car Wash

Name: Seaflo 220V 160psi Water Pump High Pressure for Car Wash
Brand: ibuyautoparts.com
SKU: 739969065
Availability: InStock
Rating: 4.4 (67 reviews)

Price:	US $ 35/Piece
Trade Terms:	FOB
Min Order:	24/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

SEAFLO 220v 160psi water pump high pressure for car wash

Application:

Agriculture/Yacht / RV/Caravan pressurized water system
Sprayer fixture (Vehicle-mounted sprayer, electric sprayer)
Cleaning machine, Humidifier, Water purification, Medical apparatus
Food beverage filling & liquid transfer
Any other pressurization system

Backed SEAFLO's 1-Year Warranty!
Colors: Black or required

How a Diaphragm Pump Works

The pump is driven by an AC or DC motor
In front of the motor is a valve assembly containing two to five valve pump chambers. Each valve chamber has a diaphragm behind it in the lower pump housing. As the motor shaft turns, an internal cam positioned behind the diaphragms causes the diaphragms to be pushed forward, then back in a continuous sequence creating a suction. As this suction builds, fluid is pulled through the inlet, through the various valve chamber check valves to the outlet
The volume of flow is determined by several factors including: The number and size of the pump chambers, cam offset, operating pressure, fluid viscosity

Motor Type:	12 VDC permanent magnet, totally enclosed, non-ventilated
Amps	9.0A Max
Certification	CE, ISO9001:2008, RoHS
Flow Rate	5.5LPM/1.5GPM
Pressure	100psi/6.9bar
Port dimension	3/8" FNPT
Diaphragm	Santoprene
Valve	Viton or EPDM
Duty Cycle	Intermittent

STANDARD PUMP CONFIGURATIONS
Model	Switch	GPM/LPM	PSI/BAR	Max Draw(A)	Valves	Diaphragm	Ports	Voltage	Wire Connections
SFDP1-015-080-31	Demand	1.5/5.5	80/5.5	7	Viton	Santoprene	3/8"-18 FNPT	12V	2-Pin/Leads
SFDP2-015-080-31	Demand	1.5/5.5	80/5.5	4	Viton	Santoprene	3/8"-18 FNPT	24V	2-Pin/Leads
SFDP1-015-100-31	Demand	1.5/5.5	100/6.9	9	Viton	Santoprene	3/8"-18 FNPT	12V	2-Pin/Leads
SFDP2-015-100-31	Demand	1.5/5.5	100/6.9	4.5	Viton	Santoprene	3/8"-18 FNPT	24V	2-Pin/Leads
SFDP1-015-120-31	Demand	1.5/5.5	120/8.3	10	Viton	Santoprene	3/8"-18 FNPT	12V	2-Pin/Leads
SFDP2-015-120-31	Demand	1.5/5.5	120/8.3	5	Viton	Santoprene	3/8"-18 FNPT	24V	2-Pin/Leads
SFDP1-015-160-31	Demand	1.5/5.5	160/11.0	12	Viton	Santoprene	3/8"-18 FNPT	12V	2-Pin/Leads
SFDP2-015-160-31	Demand	1.5/5.5	160/11.0	6	Viton	Santoprene	3/8"-18 FNPT	24V	2-Pin/Leads
SFDP1-018-080-31	Demand	1.8/7.0	80/5.5	9	Viton	Santoprene	3/8"-18 FNPT	12V	2-Pin/Leads
SFDP2-018-080-31	Demand	1.8/7.0	80/5.5	4.5	Viton	Santoprene	3/8"-18 FNPT	24V	2-Pin/Leads
SFDP1-018-100-31	Demand	1.8/7.0	100/6.9	10	Viton	Santoprene	3/8"-18 FNPT	12V	2-Pin/Leads
SFDP2-018-100-31	Demand	1.8/7.0	100/6.9	5	Viton	Santoprene	3/8"-18 FNPT	24V	2-Pin/Leads
SFDP1-018-120-31	Demand	1.8/7.0	120/8.3	12	Viton	Santoprene	3/8"-18 FNPT	12V	2-Pin/Leads
SFDP2-018-120-31	Demand	1.8/7.0	120/8.3	6	Viton	Santoprene	3/8"-18 FNPT	24V	2-Pin/Leads
SFDPA1-015-120-31	Demand	1.5/5.5	120/8.3	0.8	Viton	Santoprene	3/8"-18 FNPT	110V	Leads
SFDPA2-015-120-31	Demand	1.5/5.5	120/8.3	0.5	Viton	Santoprene	3/8"-18 FNPT	220V	Leads
SFDPA1-015-160-31	Demand	1.5/5.5	160/11.0	1.1	Viton	Santoprene	3/8"-18 FNPT	110V	Leads
SFDPA2-015-160-31	Demand	1.5/5.5	160/11.0	0.6	Viton	Santoprene	3/8"-18 FNPT	220V	Leads

Prod Model:	SFDPA2-015-160-31
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Product:	Water Pump High Pressure for Car Wash
Port Dimension:	3/8" NPT
Flow Rate:	5.5lpm/1.5gpm
Diaphragm:	Santoprene
AMPS:	1.1A Max
Protection:	Thermal/Ignition Protection
Pressure:	160psi/11.0bar
Voltage:	220V DC Permanent Magnet, Totally Enclosed, Non-Ve
Duty Cycle:	Intermittent
Valve:	Viton
Fuel:	Electric
Material:	Metal
Condition:	New
Application:	Industry
Certification:	Ce, ISO9001:2008, RoHS

Who we are

. Mini Pump Specialist

. Injection Molding Designer

. Electric sprayer provider

. Original Equipment Manufacturer

Fuan Aidi Electric Co. Ltd, established in 2004, located in Qinxiyang Industrial pack, Fuan city, which is well known as "city of electric machinery and appliances" in China. We are a modern enterprise dealing with developing, manufacturing and selling of Motor, water pump, outdoor electric appliance, drainage system of yachts and complete set of equipment.

We established excellent and high efficient working team based on People-oriented, Quality-oriented management...We follow "Quality is the root, customer is the tenet" and supply the quality product and circumspect service wholeheartedly.

"SEAFLO" brand DC diaphragm pump, DC bilge pump, livewell pump, paddle are exported to more than 30 countries including USA, UK, Germany, France, NETHERLAND, Greece, Italy, Spain Turkey, Brazil. Our products deserve high reputation among our clients due to the top quality and competitive price.

We focus on the product quality, promote work efficiency and improve the service quality. The whole staff will make unremitting endeavor to develop high quality product which meets the client and market's requirement, bring back a report to every client from domestic and abroad who always support and pay close attention to the development of the company.

Fuan Aidi Electric Co. Ltd sincerely welcome friends both domestic and abroad to work and create splendent future together!
