New Year Hot Sale Automotive Spray Booth Only Need $5300
| Price: |
US $ 5300/Piece |
| Trade Terms: |
FOB |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T |
How spray booth working
A. During painting, spray booth can offer a sealed environment with cleanness, safety and excellent lighting for the painting operation of all kind of components and different products. B. During baking, drying time, temperature and humidity in spray booth can be set according to different paint materials to achieve a perfect high-quality spraying and baking for your cars. C. Spray booth makes spraying and baking operation with no limits of all kinds of whether, thus ensuring physical fitness of operators and absolute safety of equipments. WarrantyThe goods are guaranteed for 24 months from the date of receipt, but the filters and lamps are not guaranteed. It cannot be applied for damages caused by negligence of operations or mishandling of the machine. | Outside Dimension (mm) | 7006*5350*3450(L*W*H) | Inside Dimension(mm) | 6900*4000*2650(L*W*H) |
| Front Door(mm) | 3000*2600(W*H) | Service door (mm) | 1800*650(W*H) |
| Total Power | 9.5KW |
| Cabin system | Wall panel | 50mm EPS sandwich panel, steel sheet thickness: 0.426mm |
| Ceiling panel | 0.8mm Galvanized steel sheet. |
| Basement | 300mm depth, two rows grids and three rows checkered plates. |
| Ramps | Two pieces 2000*600mm ramps |
| Glass | 4mm safety tempered glass |
| Windows | Rubber glass window |
| Air Make-up System | Air Inlet fan system | 1*7.5kw turbo fan |
| Exhausted fan system | For option |
| Ai capacity | 22000m3/h |
| Air Flowing speed | 0.25m/s in empty booth |
| Exhausted ducting | 4meters straight ducting, one 90°elbow and one 30°elbow. |
| Purification System | Pre-filter | G3 grade |
| Ceiling filter | EU5 / F5 |
| Floor filter | green fiber glass filter / G3 grade |
| Exhausted fan Filters | fiber glass filter and active carbon |
| Heating System | Heat Exchanger | SUS304 material, argon arc welding. |
| Heating burner: | BT14 diesel oil burner(gas burner for option) |
| Heating productivity | 140000Kcal/h |
| Spray to baking switch | Pneumatic damper |
| Chimney ducting | 3 meters stainless ducting and one chimney elbow |
| Max heating temperature | 80ºC |
| fuel consumption | 6-8L/vehicle |
| Lighting System | Ceiling lights | 8 Units, each 4 * 36W Philips lamps. Total 1152 W |
| Side lights | For option |
| Illumination | 900LUX |
| Controlling system | Switched control panel | Spraying & baking switch, lighting switch, emergency stop, breakdown alarm, failure alarm |
| Prod Model: |
JZJ-9100 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
6900*4000*2650(mm) |
| Certification: |
CE |
| Airflow Direction: |
Fully Undershot-type |
| Heating Mode: |
Diesel |
| Paint Mist Treatment: |
Dry-type |
| Condition: |
New |
| Brand: |
Jzj |
Jiangsu Jingzhongjing Industrial Paint Equipment Co., Ltd, is located in the Yangtze River Delta Economic Zone, China Industrial Painting Base, Yancheng city, Jiangsu Province. We have the plant area of 99000m2, garden-style industrial zone. We have the staff of 260, including 20 engineers with 15years designing experience. Our annual production capacity can achieve 2, 500 sets paint booth.
We adhere to the "heritage of big business style, classic gaming counterparts, - creating the world brand" core values. Pursuit high goals, has won wide recognition and praise from the government and the market.
Our products are JZJ Brand spray booth, sandblasting booth, shot blasting machines etc. Our products have passed the ISO9001, EU CE, the products have been shipped in the domestic 34 provinces and more than 50 countries like Germany, Japan, Russia etc.
Our products are well-known in the industrial of the automobile, aviation, military, wind power, nuclear power, engineering machinery, machine tool manufacturing, and other industries.
Welcome the customers from China and all over the world to join us!
