8CH ,4CH HD mobile DVR
With GPS,G-sensor,motion detection,3G/4G/wi-fi
Ÿ Built-in high performance Hisilicon chipsets, coded with H.264 standard, high compression rate and image qulity
Ÿ 8CH AV Inputs with AHD 1080N/720P/960H/D1/CIF optional, 1CH synchronized AV output, 1CH VGA output
Ÿ 8CH local recording with 1080N resolution in real time
Power:
Ÿ Professional In-Vehicle power design, Linear power IC 8-32V DC Wide Voltage Range
Ÿ Multi protection circuits like under-voltage, short, reversed plug-in
Ÿ Smart power management system, shutdown under low voltage, low consumption
Data Storage:
Ÿ Special file management system to encrypt and protect the data
Ÿ Proprietary technology to detect the bad track of the hard drive which can make sure the continuity of video and long service life of the hard drive
Ÿ Built-in ultracapacitor, avoid data loss and sd card damage caused by sudden outage
Ÿ Support 2.5 inch HDD/SSD, maximum 2TB
Ÿ Support SD card storage, maximum 256GB
Ÿ Support hard disk heating
Transmission Interface:
Ÿ Support 3G/4G transmission, LTE/HSUPA/HSDPA/WCDMA/EVDO/TD-SCDMA
Ÿ Support GPS/BD optional, high sensitivity, fast positioning
Ÿ Support wireless download by WiFi, 802.11b/g/n, 2.4GHz
|
|
| Technical parameter: |
| Item | Device parameter | Performance |
| System | Main processor | Hi3520DV300 |
| Operating system | Embedded Linux OS |
| Operating language | Chinese/English |
| Operating interface | GUI, support mouse |
| Password security | User password/Admin password |
Audio
&
Video
| Video standard | PAL/NTSC |
| Video compression | H.264 |
| Image resolution | 1080N/720P/960H/D1/CIF |
| Playback quality | 1080N/720P/960H/D1/CIF |
| Compound mode | A variety of ways |
| Image display | Single/split/QUAD display optional |
| Audio Compression | G.726 |
| Audio recording | Audio & Video synchronized recording |
| Recording & Playback | Recording mode | Manual/Alarm |
| Video bit rate | Full frame 4096Mbps,6 classes image quality optional |
| Audio bit rate | 8KB/s |
| Storage media | SD card + HDD/SSD storage |
| Video inquiry | Inquiry by channel/Recording type |
| Local playback | Playback by file |
| Firmware upgrading | Upgrading mode | Manual/Automatical/Remote |
| Upgrading method | USB disk/Wireless network/SD card |
| Interface | AV input | 8ch aviation interface |
| HDD/SSD | 1 HDD/SSD (up to 2TB, support hot plug/unplug) |
| SD card | 2 SDXC High speed card (up to 256GB) |
| USB interface | 1 USB 2.0 (support U disk/mouse) |
| Ignition input | 1 ACC signal |
| UART | 1 LVTTL Level |
| LED Indication | PWR/RUN |
| Disk lock | 1 |
| Debug port | 1 |
| Function extention | GPS/BD | Support detecting antenna Plug in/Unplug/Short circuit |
| 3G/4G | Supports CDMA/EVDO/GPRS/WCDMA/FDD LTE/TDD LTE |
| WIFI | 802.11b/g/n, 2.4GHz |
| Others | Power input | 8~32V DC |
| Power output | 5V 300mA |
| Power consumption | Standby 3mA
Maximum consumption 30W @12V 2.5A @24V 1.25A |
| Working temperature | -25 --- 80ºC |
| Storage | 1080N 1.2G/h/channel
720P 1G/h/channel
960H 750M/h/channel |
