Vertical Honing Machine (3MB9817)

Name: Vertical Honing Machine (3MB9817)
Brand: ibuyautoparts.com
SKU: 774016565
Availability: InStock
Rating: 4.9 (147 reviews)

Price:	US $ 1-6000/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Product Description

The machine is mainly used for honing single line engine cylinders and V-engine cylinders of automobiles motor cycles and tractors and also for other machine element holes.

Features

1. The machine table can shift of the fixture change 0° , 30° And 45° .

2. The machine table is easily up and down manually 0-180mm.

3. Reverse precision 0-0.4mm.

4. Select mesh-wire degree 0° - 90° Or non-mesh-wire.

5. Reciprocating speed of up and down 0-30m/min.

6. The machine is reliable performance widely use honing, easy operation and high productivity.

7. Good rigidity, amount of cutting.

Parameters
Model	3MB9817
Max diameter of hole honed	Φ 35- Φ 170 mm
Max depth of hole honed	320 mm
Spindle speed (4 steps)	120, 160, 225, 290 mm
Stork (3 steps)	35, 44, 65 s/min
Power of main motor	1.5 Kw
Power of cooling pump motor	0.125 Kw
Machine working inside cavity dimensions (LxW)	1400 x 870 mm
Overall dimensions (L x W x H)	1640 x 1670 x 1920 mm
Packing dimensions (L x W x H)	1850 x 1850 x 2150 mm
N.W./G.W.	1000/ 1200 kg

Prod Model:	3MB9817
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model:	3MB9817
Max Depth Of Hole Honed:	320mm

ACE MACHINE TOOLS Co., Ltd, is a specialized exporter and manufacturer of machine tools and accessories with a long history.

Our mechanical products cover more than 80 kinds including lathe, milling machine, drilling machine, grinding machine, power press, hydraulic guillotine, hydraulic press brake, CNC & automotive machines and so on.

Our customers are widespread in more than 30 countries including U. S. A., Germany, Spain, France, England, Greece, Finland, Norway, Canada, south America, Middle East, Australia, Africa and southeast Asia etc.

Our principle to all the customers is high quality and good service. We have quality control team who will carefully inspect every machine in workshop before packing.

Welcome you to visit our website and contact us. We will give you quick response upon any of your need.
