Test Bench for Automobile Air Compressor
| Price: |
US $ 9000/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Western Union |
QYZ-2 Model Automobile Braking System Test Bench1.Technical Parameter
Working power: AC380V 50HZ (Made to measure)
Motor power: 5.5KW
Variable frequency speed regulating range:
no load 0-5000r/min
load 0-2000r/min(continuously adjustable)
Volume of main air tank: 20L*2 or 20L*3
Volume of sub air tank: 2L*3
Auxiliary tank of air pump: 15L
Requirement of external air source: 0.85Mpa
Microcomputer hour meter: 000.000--999.999S(adjustable)
Rated pressure of oil pump: 0.3MPa
2. Function Introduction (double-chamber or three-chamber test)
This air braking test bench is used mainly for testing performance of air compressor, master valve, air chamber, quick release valve and four-circuit valve in brake system of high, medium and low models automobiles at home and abroad and carrying out double-chamber or three-chamber test of master valve.
Test Items:
air compressor: The time required by air compressor to reach specified pressure value when air compressor runs at rated RPM.
Master valve: the required time of inflating air from main tank into air chamber through master valve (the time through air);
Air chamber: after air is inflated from main tank into air chamber to reach set pressure value, hold the pressure.
Quick release valve: after air is inflated from main tank into sub-tank through quick release valve to reach set pressure value, hold the pressure.
Four-circuit valve: the same with test of quick release valve.
MOQ: 1 set
Panel: English
Delivery time : 35days
Payment term:
T/T 50% in advance,50% before delivery
Packing :
Export Plywood case
1700*950*1680=2.71CBM1040*745*1330=1.03CBM
Total:3.74CBM
G.W: 520KGS
N.G: 400KGS
| Prod Model: |
QYZ-2 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Power: |
380V 50Hz |
| Motor Power: |
5.5kw |
| Update Method: |
by Hard Disk |
| Certification: |
ISO |
Established in 1984, Qingdao Haolida Automotive Equipment Manufacturing Co., Ltd is a professional manufacturer and exporter that is concerned with the design, development and production of automobile maintenance and test equipment. We obtained tens of national patent on some related products. Our main products are automobile test benches, such as electric universal test bench, alternator/generator test bench, starter test bench, engine test bench, turbocharger test bench, air compressor test bench, braking system test bench, steering gear and power pump test bench, AC compressor test bench, clutch test bench, automatic gearbox/transmission test bench, etc, brake shoe riveting and grinding machines, electric/ manual hydraulic presses, auto pit jack/lift, and so on. We can also design and make specially according to customers' request.
We are located in Qingdao city, Shandong province, with convenient transportation access. Our factory is thirty minutes' drive to Qingdao airport, and two hours' drive to the loading port.
All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world. We have passed the ISO9001-2008 international quality system authentication. We gained many honors in automobile maintenance and repair industry, we are a standing member of the China Automobile Maintenance and Repairing Equipment Trade Association, One of the ten most influential company in automobile maintenance and repair industry, we are also a designated factory by General Armament Department of CPLA.
Our well-equipped facilities and excellent quality control throughout all stages of production enable us to guarantee total customer satisfaction. Our sales network covers North America, South America, European, South Africa, Russia, Asia, Middle East, etc.
If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are also sincerely looking for steady and long-term cooperative local agents in different areas. We are looking forward to forming successful business relationships with new clients around the world in the near future.
