Outside Size(mm): 7046*5896*4175
Inside Size(mm): 7000*4000*2650
Front Door(mm): 3000(W)*2600(H)
Service Door(mm) 650 * 1800 Total Power 26kw
Wallboard: EPS colorful steel skin board, wall panel: 70mm thick, ceiling panel: 50mm thick rock-wool panel. The side door with a pressure lock which will automatically open when the pressure inside is over-pressure
Basement: Full grids, adjustable height, galvanized steel sheet construction, three embossed steel ramp
Inlet Fan Model: YDW4.5L
Outlet fan Model: 4-82-6.3E
Capacity: 24000m3/h
Capacity: 30000m3/h
Power: 4kw Power: 11kw
Quantity: 2 sets
Quantity: 1 set
The circulation system covers a set of automatic valve and two sets of manual valve. Manual adjustment valves are placed in inhaling and exhaust duct to control airflow volume and adjust pressure. A stainless steel trapezoid hood and a stainless cone hood.
36 pcs ceiling nozzles with 2 centrifugal fans(1.5kw/set) & two corner dryers for drying water based paint
Purification System: Dual filtering structure, the primary filter can capture granules larger than 10 μ M. Ceiling filter can capture granules bigger than 4μ M. The whole purification system has capacity of large volume of dust. Its filtering rate reaches 98%. Air pressure balance gauge, TSP≤ 1.2mg/m3
Heating System: Italy Riello RG5S diesel burner, 260000Kcal/h, 20N damper motor Heating exchanger, stainless steel, argon arc welding, heating exchange rate 85% max temp: 80, heating time: 6-10min(20-60), fuel consumption: 6-8kg/vehicle
Lighting System: Ceiling Light: 32pcs 36w Philips lamp; Bottom light: 32pcs 20w Philips lamp, 1100 Lux
Controlling System: PLC digital controlling, soft touching button, spray & baking switch, light switch, emergency stop, breakdown alarm
Environmental System: No-pump water curtain for mist filtering device can reduce more than 98% of the fog without the trouble of replacing drying-method filter by fully mixing fog, water and air, and ensure a qualified exhaust according to the relevant state standards
