Name: Mvha-2p Series Mindman Air Push Button Valve Mindman Type
Brand: ibuyautoparts.com
SKU: 788350585
Availability: InStock
Rating: 4.5 (89 reviews)

Price:	Negotiable/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

MVHA Series Air Push Button Valve may be operated by pilot, mechanical or solenoid operators or manually operated by their push-buttons. Each push-button's shoulder bottoms-out on the valve body to prevent overstroke and valve damage. Operators adapt directly to the threaded button end on push button valves. The push button itself is constructed of work-hardened stainless steel. Appropriate lock-nuts and lock-washers are furnished.

Model	MVHA-2P MVHA-3P MVHA-2V MVHA-3V
Bore	M5
Port Size	M5×P0.8
Normal Type:	Normal Closed
Number of port	2 or 3
Medium	Air
Operating pressure range	0~0.9Mpa
Orifice	1.8mm
Temperature	-5~60 degree
Weight	30g

Standard or Nonstandard:	Standard	Structure:	Pilot	Pressure:	Low Pressure
Power:	Manual	Material:	Alloy	Temperature of Media:	Low Temperature
Media:	Air	Port Size:	M5	Place of Origin:	Zhejiang China (Mainland)
Model Number:	MVHA-2P Air Push Button Valve	Brand Name:	VPC Air Push Button Valve	Application:	air bag
working temperature:	-10~55ºC	Material:	Aluminum	Working medium:	Clean Air

Prod Model:	MVHA-3P
