Home Garage Scissor Car Parking Lift for Residential
| Price: |
US $ 5900-7200/Piece |
| Trade Terms: |
FOB,CFR,EXW |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Western Union |
Home Garage Scissor Car Parking Lift for ResidentialDetailed information:
1) Load capacity: 4000kgs
2) Platform size: 5500*3300mm
3) Lift height: 3500mm
4) Power: 380v/50hz/3ph/5.5kw/customized
5) Control system: 1 control box, 1 control panel
6) Control buttons up, down, stop, emergency
7) Safety device: explosion-proof lock valve
8) Standard: CE
Safety:
1) Explosion-proof lock valve to avoid a sudden drop if emergency occurs
2) The safe rails to guarantee safety of the car above platform
3) The limit switch system helps the car lift to stop at accurate position.
4) Electricity leakage protection device is equipped on, all electric components are CE
certified.
5) All the hydraulic car elevators are passed 1.2 times loading test before leaving factory.
Application:
The scissor car lift can be used to lift car with different levels, suitable for car moving
between stairs, from basement to first floor, or to second floor. Custom-made product
are made according to detailed request, please tell us load weight, lift height, and
platform size, our engineer will design a suitable hydraulic scissor car lift for you soon.
Specifications and Safety:
1. Scissor hydraulic car parking system can be used to lift cars with different levels, suitable for car moving between stairs, from basement to first floor, to second floor, or to third floor. Operation is easy, and the lifts run very smoothly. There are explosion-proff lock value to avoid a sudden drop if emergency occours.
2.The hydraulic cylinders and hoses are armed with explosion-proof lock valve that aims to avoid a sudden drop in case hydraulic pipe breaks, the work platform will drops slowly to ensure car's safety .
3. Emergency button is available on each control box, when emergency occurs, the immediate STOP can be realized.
4.The handrail guarantees the safety of cars. Equipped with 4 guide rails to ensure safety and steady.
5. There are 2 sets control systems are installed on the lift, 1 control box below and 1 control panel on the handrail that can be operated on work platform.
6. The limit switch system ensures lifts stop at accurate position.
7. Overload protection facility will protect the lift from working when goods are overloaded.
8. Electric control system is adopted from the elevator control system of Japan Mitsubishi that ensures the safety of lift.
9. Custom-made products are done according to detailed request, please tell us your load capacity, lift height, and platform size you need, we can customize for you.
10. Guarantee period: 12 months. We supply spare parts free and supply technical supporting all the time.
Parameters:
Model | SJG4-3.5 |
| Lifting capacity | 4000kg |
| Lifting height | 3500mm |
| Size of platform |
5500 * 3300 mms.
( Diamond steel sheet metal )
|
Motor power | 5.5kw |
| Power supply | AC 220V/380V 50HZ/60HZ |
| Speed | 100mm/s |
| Weight | 1850KG
|
Pictures:
| Prod Model: |
SJG |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Platform Size: |
5500*3300mm |
| Load Capacity: |
4000kg |
| Travel Height: |
3500mm |
| Self-Height/Closed Height: |
840mm |
| Drive: |
Hydraulic |
| Speed: |
100mm/S |
| Structure: |
Scissor Type |
| Installation: |
Pit Installation |
| Type Of Work: |
Special Weight Level |
| Warranty: |
12 Months |
| Type: |
Four Cylinder Hydraulic Lift |
| Lifting Capacity: |
3.5T |
| Certification: |
CE |
| Design: |
Scissor |
| Brand: |
Moral |
