High Definition Car Rear View Mirror for Bus

Name: High Definition Car Rear View Mirror for Bus
Brand: ibuyautoparts.com
SKU: 755267815
Availability: InStock
Rating: 4.6 (134 reviews)

Price:	US $ 65/Piece
Trade Terms:	FOB,EXW
Min Order:	1/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

High Definition Car Rear View Mirror for Bus

Key Feature:
- 3.5" digital TFT LCD monitor
- High resolution video rearview camera
- 5M extension cable with RCA connector
- Car rearview system
Monitor Specifications:
- Screen size: 3.5" digital TFT-LCD
- Display Format: 640 x 240 Dot
- System: PAL/NTSC
- One video input
- Viewing angle: right/left/up/down 40°/40°/20°/50°
- Brightness: 250cd/m2
- Operation Temperature: -20~70°
- Temperature Range Storage -30~80°
- Power consumption: 2W
- Power requirement: DC 12V
Camera Specifications:
- Image Device: 1/4" CMOS image sensor
- TV System: NTSC/PAL.
- View Angle: 170°
- Waterproof design
- Effective Pixels: 510*496pixels
- Sensing Area: 5.961mm*4.276mm
- Resolution: 420TV lines
- Minimum Illumination: 0.01Lux
- Video Output: 1.0vp-p, 75Ohm
- Gamma Consumption: 0.45
- White Balance: Auto
- S/N Ratio: Better than 48dB
- Electronic Shutter: 1/60S-1/5000S
- Power Supply: DC12V
- Operating Temperature: -20° to +70°RH95%Max
- OmniPixel technology for low-light performance

Screen size	3.5inch
Resolution	800480RGB
System	PAL/NTSC automatically
Audio and video	4 video/1audio input Quad images,2/3/4 image optional
OSD menu	Language,brightness, contrast, trigger priority delay display setting
Luminance	250cd/SM
Working temperature	-20°C-+70°C
Storage temperature	-30°C-+80°C
Voltage	12V-24V DC
Connector	4 pin or RCA
Accessories	user manual/remote controller/powr calbe/sunshade/scre

Prod Model:	WS3501T/MNC03
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Display Type:	Reverse Image
Alarming Distance:	2.5-0.35m
Probe Diameter:	18.8mm
Interface:	RCA
Shell Material:	ABS Plastic
Function:	Night Vision
Chip:	CCD
Definition:	420tvl
Probe Number:	1/2/3/4
Certification:	Emark

BRVISION TECHNOLOGY Co., Ltd is a professional Mobile Electronics and Surveillance developer & supplier in China. We specializing in OEM and ODM vehicle rear view system and surveillance products

Our vehicle system department products include the heavy duty and car reversing system, TFT LCD monitor, License plate camera, wireless Module, DVR recorder camera and etc.

Our surveillance system department products line have PTZ camera, dome camera, box camera, and so on.

It is our mission statement to bring convenience to your life while protecting your safety and property. Above all, BRVISION strives to offer products for all our customer's unique requirements both in China and on the international market. Currently, our products are exported to North America, Europe, the Middle East and all over Asia.

BRVISION has decades of experience of safety and surveillance in the international market place. We can quickly respond to your feedback and are well equipped to meet any and all your requirements.

We specialize in:

. Vehicle Rearview Camera(CCD or CMOS)

. Vehicle TFT LCD Monitor

. Wireless Transmitter and Receiver

. Surveillance Camera

. OEM and ODM Project

BRVISION Certificats: CE, FCC, Emark, ISO9001-2008
