Cylinder Boring Machine (TX170A/TX200A/TX250A)

Name: Cylinder Boring Machine (TX170A/TX200A/TX250A)
Brand: ibuyautoparts.com
SKU: 781151875
Availability: InStock
Rating: 4.6 (94 reviews)

Price:	US $ 1-2/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Prod Model:	(TX 170A/TX 200A/TX 250A)
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model:	Tx 170A
Max. Boring Depth:	400mm
Max. Milling Area:	400X 1000mm

Product Description

Cylinder Boring Machine

Product Description
The speed of spindle turning and table moving can be enacted freely in the area of parameter
Spindle feeding (spindle Z) is auto pitched, the precision can be to 0.1mm
Longitudingal and cross movement of table
Complete set of accessories of boring, milling, drilling & reaming and easy exchange
Spindle fast centering device
Tool measuring device
Boring depth control device
Table with digital readout for jig borer machine

Parameters
Model		TX 170A	TX 200A	TX 250A
Max. boring diameter		Φ 170mm	Φ 200mm	Φ 250mm
Max. boring depth		400mm	500mm	500mm
Max. milling area		400x 1000mm
Max. drilling & reaming diameter		Φ 30mm
Spindle speed		120-860r/min
Feeding of the spindle		14 -900 mm /min
Rapid moving speed of the spindle		1000 mm /min
Spindle travel		700 mm
Distance between spindle end face and table		0 -700 mm
Distance between spindle axis and carriage vertical plane		375 mm
Feed of the table longitudinal		32 -1350 mm /min
Rapid moving speed of the table longitudinal travel		32 -1350 mm /min
Max longitudinal travel of working table		1500 mm
Max cross travel of the working table		200 mm
Working table size (W×L) (mm)		500x1250	500x1500
Main motor		5.5Kw
Processing roughness	Boring	Ra 2.5
	Milling	Ra 3.2
Overall dimensions (L×W×H)		2600x1630x 2300 mm
Packing dimensions (L×W×H)		2250x1900x 2280 mm
N.W./G.W. (kg)		3300/3600	3500/3800

ACE MACHINE TOOLS Co., Ltd, is a specialized exporter and manufacturer of machine tools and accessories with a long history.

Our mechanical products cover more than 80 kinds including lathe, milling machine, drilling machine, grinding machine, power press, hydraulic guillotine, hydraulic press brake, CNC & automotive machines and so on.

Our customers are widespread in more than 30 countries including U. S. A., Germany, Spain, France, England, Greece, Finland, Norway, Canada, south America, Middle East, Australia, Africa and southeast Asia etc.

Our principle to all the customers is high quality and good service. We have quality control team who will carefully inspect every machine in workshop before packing.

Welcome you to visit our website and contact us. We will give you quick response upon any of your need.
