Shenzhen Brvision Technology Co., Ltd. >> Ceiling CCD Camera /5.6inch TFT LCD Car Monitor

Ceiling CCD Camera /5.6inch TFT LCD Car Monitor

Ceiling CCD Camera /5.6inch TFT LCD Car Monitor
Price: Negotiable/Set
Trade Terms: FOB,EXW
Min Order: 1/Set
Pay Type: T/T,Paypal

Ceiling Camera for Bus /5.6inch TFT LCD Monitor
Monitor Specifications:

. Screen size: 5.6 inch Digital panel (16:9)
. Input: 2-way video input
. System: PAL and NTSC  switching
. Resolution: 320 x R.G.B x 234
. Power supply: 12-24V DC
. Bui lt-in speaker
. Heavy duty  reversing
. Remote control, OSD menu
. contrast, color, brightness adjustable
. Three video input with 2 trigger cable.
.  Operating temperature: -20ºCto +70ºC
.  Storage temperature: -30ºC to +80ºC



BR-RVC05

Camera Specification:

-  Image Sensor : 1/4" Sharp/Sony Color CCD
- TV System: N TSC/ PAL
- IP Rating: IP65
- Vibration Rate: 10G
- Ef fective Pixels N: 510×492 pixels P: 500×582 pixels
- Horizontal Resolution: 420TVL
- Video Output : 1.0vp- p,75Ohm,
- Built-in Lens:2.8mm
- Wide angle: 120°
- Power Supply: 12V DC(+/-10%)
- Power consumption: <3W
- Silver Alluminium housing.
- Oper at i ng Temp: - 20C° t o +70C°
- Storage Temp: - 30C° t o +80C°

Prod Model: TM5601&RVC05
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Screen Size: 5.6 Inch
System: PAL and NTSC Switching
Resolution: 320 X R.G.B X 234
Power Supply: 12-24V DC
Image Sensor: 1/4" Sharp/Sony Color CCD
IP Rating: IP65
Horizontal Resolution: 420tvl
Waterproof Grade: IP68
Chip: CCD
Definition: 420TVL
Interface: 4 Pin Connector
BRVISION TECHNOLOGY Co., Ltd is a professional Mobile Electronics and Surveillance developer & supplier in China. We specializing in OEM and ODM vehicle rear view system and surveillance products

Our vehicle system department products include the heavy duty and car reversing system, TFT LCD monitor, License plate camera, wireless Module, DVR recorder camera and etc.

Our surveillance system department products line have PTZ camera, dome camera, box camera, and so on.

It is our mission statement to bring convenience to your life while protecting your safety and property. Above all, BRVISION strives to offer products for all our customer's unique requirements both in China and on the international market. Currently, our products are exported to North America, Europe, the Middle East and all over Asia.

BRVISION has decades of experience of safety and surveillance in the international market place. We can quickly respond to your feedback and are well equipped to meet any and all your requirements.

We specialize in:

. Vehicle Rearview Camera(CCD or CMOS)

. Vehicle TFT LCD Monitor

. Wireless Transmitter and Receiver

. Surveillance Camera

. OEM and ODM Project

BRVISION Certificats: CE, FCC, Emark, ISO9001-2008
