ZM-280 Model Brake Lining Riveting and Grinding Machine with Dust Collector System
General introduction
It is used for riveting rivets of all kinds of brake shoes\brake disc\brake drum\brake lining \ brake pad and other auto parts.
It can grind brake shoes to proper size.
Advantages:
1.It uses air source as power.
2.It is suitable for heavy duty truck brake lingings,etc.
3.Pressure can be adjusted according to size and material of the rivets.
4.Pedal room is big.
5.It is matched with dust collecting system, to collect dust, it is environment friendly.
6.Good discount based on order quantity
Technical parameter:
| Model no | ZM-280 |
| Material | Metal plate |
| Painting | High quality paint |
| Color | Blue&black |
| Max rivet force | 60KN(6T) |
| Suitable rivet diameter | 3-10mm |
| Power | 1.5KW |
| RPM of grinding wheel spindle | 3000r/min |
| Max grinding width | 280mm |
| Accessories: |
Riveters: 6pcs, used for working on Φ3, Φ4,Φ5,Φ6,Φ8,Φ10 rivets
Puncher: 2pcs, used to remove old rivets 3mm-10mm |
| Others you may want to know: |
| MOQ | 1set |
| Warranty period | 12 months |
| Payment term | T/T 100% in advance |
| Delivery time | 10days after receiving downpayment |
| HS code | 8463900090 |
| Packing sizes | Export plywood case
1300*780*146mm=1.48CBM
N.W: 90kgs
G.W: 120kgs |
