Basement Double Platform Car Parking Lift
| Price: |
US $ 4000-7850/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Western Union |
| Prod Model: |
SJC |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Load Capacity: |
5000kg |
| Platform Size: |
5800*2800mm or Customized |
| Lifting Height: |
2500mm or Customized |
| Speed: |
6m/Min |
| Power: |
5.5kw |
| Materials: |
Mn Steel |
| Working Condition: |
Inddor or Outdoor |
| Driving Mechanism: |
Hydraulic |
| Safety: |
Lead Rail |
| Warranty: |
12 Months |
| Type: |
Double Cylinder Hydraulic Lift |
| Lifting Capacity: |
≥5T |
| Certification: |
CE |
| Design: |
Scissor |
| Brand: |
Moral |
Product Description
Basement Double Platform Car Parking LiftDouble deck vehicle parking system heavy-duty scissors style lift Designed to lift up to two 7,000 lbs. vehicles simultaneously.
The deck structure and components are completely concealed below ground so there is no indication
that a lift (or second car) is present when lowered. The Double deck car platform, a unique breed of lift
for the uncompromising property owners that need affordable parking space.This 2-deck drive-on lift is
a smart solution for both commercial and residential applications.Main Features:Load capacity: 5000kg
Platform size: 5.8*2.8m
Lifting height: 2500mm
Hydraulic drive systemMain Description:1) Scissor hydraulic car parking system can be used to lift cars with different levels, suitable for car moving between stairs, from basement to first floor, to second floor, or to third floor. Operation is easy, and the lifts run very smoothly. There are also explosion-proof lock valve to avoid a sudden drop if emergency occurs.
2) The limit switch system helps the lift to stop at accurate position.
3)The hydraulic cylinders and hose are armed with explosion-proof lock valve to avoid a sudden drop once hydraulic pipe breaks, the work platform will be down slowly to ensure safety of car.
4) Emergency button is available on each control box, when emergency occurs, the immediate STOP can be realized.
5) Control system adopt elevator control system, very convenient and safety.
6) Custom-made products are done according to detailed request, please tell us load capacity, lift height, and platform size you need, our engineer will design a suitable lift for you soon.Parameters: | Model | SJG5-2.5 |
| Lifting capacity | 5000kg |
| Lifting height | 2500mm |
| Size of platform |
5800 X 2800 mms.
( Diamond steel sheet metal )
|
| Motor power | 5.5kw |
| Power supply | AC 220V/380V 50HZ/60HZ |
| Speed | 100mm/s |
| Weight | 2950KG |
Pictures:
Welcome to the on-line home of Moral lift Machinery Co., Ltd. Our factory is one of the leading manufacturer of Disabled weelchair lifts & scissor lift &parking equipment&Work platform&Horse trailer in China. Our mainly product including wheelchair lift, car parking lift, car turntable, cargo lift(VRC and scissor lift), work platform and Horse trailer etc.
With over 4 decades of experience in the manufacture of materials handling products, Morallift' S skilled team of friendly personnel can provide fast responses and technical expertise. Our product has got ISO9001: 2000 Quality Certification and has passed the test of CE Quality system as well. We always provide our customers with the best quality products, competitive prices and excellent services.
Our customers from around the world, We regard "reasonable prices, efficient production time and good after-sales service' ' As our tenet, and hope to cooperate with more customers for mutual development and benefits. We welcome every potential customer to visit our factory!
