Prod Model: |
SJG |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Load Capacity: |
4000kg |
Platform Size: |
5500*2500mm |
Lifting Height: |
5000mm or Customized |
Speed: |
100mm/s |
Control: |
Button/Remote control |
Platform: |
Anti-skid steel top |
Power: |
5.5 Kw |
Pit Depth: |
560mm |
After-Sale Service Provided: |
Overseas Service Center Available |
Warranty: |
12 Months |
Type: |
Double Cylinder Hydraulic Lift |
Lifting Capacity: |
4T |
Certification: |
CE |
Design: |
Scissor |
Double Cylinder Lift Type: |
Hydraulic Cylindar |
Brand: |
Moral |
Product Description
Automated Basement Pit System 2 Level Car Parking Lift A cost effective and smart solution for both commercial and residential parking applications.
Load : 3000kg. Other loads and sizes on application are available
Ideal for outdoor installation such as in gardens or garage access zones, Duplo can double up parking spaces or hide vehicles completely underground, keeping the residential space free of clutter.
The platform can also be used for full size vehicles or those with a long wheel base.
The roof has an access hatch for maintenance, control and emergency access.This opening makes inspection easier, even during closed parking of unit.
Main Features:Load capacity: 4000kg
Platform size: 5.5*2.5m
Lifting height: 5000mm/custom
Hydraulic drive systemMain Descriptions:1) scissor hydraulic car parking system can be used to lift cars with different levels, suitable for car moving between stairs, from basement to first floor, to second floor, or to third floor. Operation is easy, and the lifts run very smoothly. There are also explosion-proof lock valve to avoid a sudden drop if emergency occurs.
2) The limit switch system helps the lift to stop at accurate position.
3)The hydraulic cylinders and hose are armed with explosion-proof lock valve to avoid a sudden drop once hydraulic pipe breaks, the work platform will be down slowly to ensure safety of car.
4) Emergency button is available on each control box, when emergency occurs, the immediate STOP can be realized.
5)control system adopt elevator control system, very convenient and safety.
6)Custom-made products are done according to detailed request, please tell us load capacity, lift height, and platform size you need, our engineer will design a suitable lift for you soon.Parameters: Model | SJG4-5 |
Lifting capacity | 4000kg |
Lifting height | 5000mm |
Size of platform | 5500 X 2500 mms.
( Diamond steel sheet metal )
|
Motor power | 5.5kw |
Power supply | AC 220V/380V 50HZ/60HZ |
Speed | 100mm/s |
Weight | 2950KG |
Pictures:
