| Prod Model: |
SC02-N |
| Bluetooth Password: |
1234 or 0000 |
| After-Sale Services: |
One Year Warranty |
| Elm327 Function: |
ECU Code Reader |
| Applied To: |
OBD 16 Pin Gasoline Vehicels |
| Delivery Time: |
Within 1 Day After Payment |
| Chips: |
Pic18f25K80 |
| Operation System: |
Android&PC |
| Connect Way: |
by Bluetooth |
| Model Name: |
Mini Elm327 Bluetooth |
| Update: |
by Email/CD |
| Update Method: |
by Email |
| Testing Equipment Type: |
Code Reader |
Product Description
ELM327 Vgate Scan V1.5 Version
Top Reason to Choose V1.5 Hardware:
1. PICI8F25K80 Chip, real ELM327 1.5 version support 9 protocol include SAE-J1850 PWM , JAE J1850 VPW(for F-ord old cars and for G M old cars use this protocol like Explorer 1998 )
2. Higher Quality. Say NO to poor quality , Save your time and money!
3. More support , provide useful app for ELM327 Like TORQUE
4. If the CD is broken,pls download software from: 360diag.net . sorry for the inconvenience to you,please never open a dispute before contact with the seller.
Features:
OBD SCAN is the newly developed wireless scan tool. It supports all OBD-II protocols
0.Automatic
1.SAE J1850 PWM(41.6Kbaud)
2.SAE J1850 VPW(10.4Kbaud)
3.ISO9141-2(5 baud init,10.4Kbaud)
4.ISO14230-4 KWP(5 baud init,10.4 Kbaud)
5.ISO14230-4 KWP(fast init,10.4 Kbaud)
6.ISO15765-4 CAN(11bit ID,500 Kbaud)
7.ISO15765-4 CAN(29bit ID,500 Kbaud)
8.ISO15765-4 CAN(11bit ID,250 Kbaud)
9.ISO15765-4 CAN(29bit ID,250 Kbaud)
A.SAE J1939 CAN(29bit ID,250*Kbaud)
B.USER1 CAN(11*bit ID,125*Kbaud)
C.USER2 CAN(11*bit ID,50*kbaud)
*default settings(user adjustable)
1.Works with all OBD-II compliant vehicles
2.Wireless (Bluetooth) 5~10 meter
3.Software included for Palm, PDA,Mobile
4.Software included for Windows PC
5.Software included for Windows Smartphone
Functions:
1.Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database).
2.Clear trouble codes and turn off the MIL ("Check Engine" light)
3.Display current sensor data, including:
4.Engine RPM
5.Calculated Load Value
6.Coolant Temperature
7.Fuel System Status
8.Vehicle Speed
9.Short Term Fuel Trim
10.Long Term Fuel Trim
11.Intake Manifold Pressure
12.Timing Advance
13.Intake Air Temperature
14.Air Flow Rate
15.Absolute Throttle Position
16.Oxygen sensor voltages/associated short term fuel trims
17.Fuel System status
18.Fuel Pressure
19.Many others...
Delivery time Note: If your Confirmation Time is coming, you still not receive the goods, please contact us, we will extend the delivery date in advance.
No Dispute please: Please do not apply dispute within 60 days, let's keep good business relationship. Thanks for your kind understanding
Shenzhen Kingbolen Electrics Technology Co., Ltd., founded in 2005, is a comprehensive enterprise dedicated to the research, development, manufacture and international sale of automotive diagnostic tools, auto key programmers, odometer correction tools, auto programmers and auto cables, such as launch X431 PRO, X100 PAD, X100 PRO, VAS5054, LEXIA3, CAN Clip, CDP, Digimaster3, Handy-Baby, VAG cable and so on.
We provide OEM/ODM services for customers around the world. We have established a global network that helps us work closely with customers and met customer's requirements in a faster speed. Kingbolen has established long-term strategic relationships with many Chinese factories in automotive electronic industries. Currently, we are exporting more than 95% of our products to clients in West Europe, USA, Africa, Southeast Asia and the Middle East. We have implemented a comprehensive quality control system.
Our company persists in the service goal of "Quality, honesty, professionalism and innovation". We do hope "Kinbolen" will become world famous brand in the near future.
