Konnwe Kw680 OBD2 Eobd Can Automotive Scanner Support SAE J1850 Protocol Full OBD 2 Functions Diagnostic Multi-Language Pk Om126

KONNWEI KW680 OBD2 / EOBD / CAN Car Diagnostic Scanner
 ( Send 2 gifts afterplacingorder)



Top 9 Reasons to Choose KW680  OBD2 Automotive Scanner:

1. Multilingual diagnostic interface: KW680 Supports up to 8 different languages user interface,
English, Spanish, Portuguese, French, Russian, German, Dutch, Italian
2. Works on ALL 1996 and newer vehicles (OBDII & CAN) - domestic and import
3. High Quality and High Resolution TFT colorful display .
4. Bright color coded LEDs and built-in speaker .
5. Brand New design Key pad, unique patented One-Click I/M Readiness Key, it is the best partner for your car repairing.
6. Featured battery real-time monitoring during diagnostics.
7. Intergrated memory card allows storage of Trouble Codes, Live Data and freeze frame, Playback and review data when out of vehicles.
8. Data printable through USB cable, allows modify and print-out storaged data.
9. Internet upgradable via usb port , adapted to Windows XP- Windows 7.on this link,  http://www.itoscanner.com.



OBD2 Automotive Scanner KONNWE KW680 Brief Description:

The KONNWEI KW680 OBD2 / EOBD / CAN Auto Diagnostic Scanner supports all 10 OBDII test modes on all OBDII compliant vehicles for a complete diagnosis. Featuring the unique patented One-Click I/M Readiness Key, TFT color display and built-in speaker, Real Time Battery Voltage Monitoring, the KONNWEI KW680  is truly the ultimate in power and affordability, allowing users to do their jobs faster.
In addition, thousands of troubleshooter code tips(by press" ?" button) help technicians and home DIY users to accurately diagnose even the toughest problems. With the newest friendly diagnostic interface, KW680 will be the most useful car diagnostic tool for every family and professional mechanic technician!


Packing list:

1*KONNWEI KW680 Auto Diagnostic Scanner
1*User's Manual in English
1*OBD2 Cable
1*USB Cable
1*protective nylon bag
1* Free 3D car sticker as gift


Specification:
Display:  TFT color screen ( 320*240dpi)
Operating Temperature: 0 to 60 ºC (32 to 140 ºF)
Storage Temperature: -20 to 70 ºC (-4 to 158 ºF)
Power: 8 to 18 V provided via vehicle
Supported Protocols: J1859-41.6, J1850-10.4, ISO9141, KWP2000 (ISO 14230), and CAN (Control Area Network  ISO 11898)
Dimensions: 124mm (4.88in) x 70mm (2.76'') x 20mm (0.79'')

item function

KW680 Function and Features :

1. Works on ALL 1996 and newer vehicles (OBDII & CAN) - domestic and import
2. Features the unique patented One-Click Readiness Key for quick State Emissions readiness check and drive cycle verification.
3. Bright color coded LEDs indicators and built-in speaker provide both visual and audible tone for readiness verification
4. Retrieves generic (P0, P2, P3 and U0), manufacturer specific (P1, P3 and U1) codes and pending codes
5. Easily determines the cause of the Check Engine Light(MIL)
6. Turns off Check Engine Light (MIL), clears codes and resets monitors
7. Enhanced OBD2 Mode 6 On Board Monitoring Test Results for Specific Monitored Systems.
8. Views freeze frame data
9. Displays monitor and I/M readiness status (emissions)
10. Reads live PCM datastream
11. Displays live O2 sensor test data
12. EVAP System test data
13. Live sensor data in text mode and graph mode (1996 and newer vehicles)
14. Reads, stores and playbacks live sensor data
15. Troubleshooter code tips guide technicians to the root cause of a trouble code faster, saving diagnosis and repair time
16. Battery Voltage real time monitoring.
17. Built-in DTC look-up library and display definition.
18. Retrieves vehicle information (VIN, CIN and CVN)
19. Internet updateable and upgradeable
20. Prints data via PC



software display

1. America Car List: (include Brazil)
Need standard obd2 , and release from 1998 years to now
Fit for Chrysler ,Fit for Ford ,Fit for GM ,Fit for Jeep

2. Europe Car List:
Need standard obd2 , and release from 2000 years to now
Fit for Alfa Romeo ,Fit for SAAB  ,Fit for Acura  ,Fit for Opel, Fit for Audi ,Fit for Seat  ,Fit for Peugeot ,Fit for Renault
Fit for Bentley ,Fit for Skoda ,Fit for Daewoo, Fit for Benz ,Fit for Daihatsu  ,Fit for Land Rover
Fit for BMW ,Fit for Vauxhall ,Fit for Citroen, Fit for Volvo ,Fit for Fiat ,Fit for VW ,Fit for Ford ,Fit for Jaguar

3. Asia Car List: (include Australia)
Japanese car  Need standard obd2 , and release from 2002 years to now
Fit for KIA ,Fit for Isuzu ,Fit for Honda ,Fit for Mitsubishi, Fit for Hyundai  ,Fit for Dacia  ,Fit for Lexus ,Fit for Mazda
Fit for Nissan  ,Fit for Subaru ,Fit for Suzuki, Fit for Toyota
Chinese car Need standard obd2 , and release from 2005 years to now
Fit for BYD, Fit for Chery, Fit for Geely, Fit for Great Wall, Fit for Karry

4. Russian Car List:
For Ssangyong Actyon , A200 XDI Diesel , from 2007 to 2017 years ; 2.4 Diesel , from 2009 to 2017 years.
For Ssangyong Korando , 2.0 TD Diesel , from 2013 to 2017 years.
For Ssangyong Kyron , 2.0 Diesel , from 2007 to 2017 years.
For Ssangyong Rexton , 2.7 XVT Diesel , 2007 years or 2011 to 2017 years,
For Ssangyong Rodius , 2.7 Diesel , 2007 to 2017 years.
For LADA Niva , 1.7 Gasoline , from 2011 to 2017 years.
For LADA Priora , 1.5 Gasoline , from 2008 to 2017 years.
