8CH 1080P Car Mobile DVR Support Ahd Tvi Cvi with 4G and GPS
| Price: |
US $ 150-380/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union |
H3 Series 1080P Small Size Hard Disk Mobile Digital Video Recorder MODEL: VC-H3 -4 :4ch Local RecordVC-H3-4-G :4ch Local Record+GPSVC-H3-4-G -H :4ch Local Record+GPS+3G(WCDMA)VC-H3-4-G -H-W :4ch Local Record+GPS+3G(WCDMA)+WIFIVC-H3-4-G -4G :4ch Local Record+GPS+4GVC-H3-4-G -4G-W :4ch Local Record+GPS+4G+WIFI VC-H3-8 :8ch Local RecordVC-H3-8-G :8ch Local Record+GPSVC-H3-8-G -H :8ch Local Record+GPS+3G(WCDMA)VC-H3-8-G -H-W :8ch Local Record+GPS+3G(WCDMA)+WIFIVC-H3-8-G -4G :8ch Local Record+GPS+4GVC-H3-8-G -4G-W :8ch Local Record+GPS+4G+WIFI VC-H3 Series is a 1080P MDVR withing 1pcs hard disk +1pcs SD Card . specially designed for analogy project solution's upgrade directly purpose,it can supply very good quality picture to show the details more clearly without rewiring. Support 4 channel real time 1080P video and 4 channel audio recording, or support 8ch 1080P AV as 8ch HD record solution. - Industrial level design;
- H.264 advanced audio/video compression technology;
- 4ch model support max 4ch 1080P video input,4 ch audio input;
- 8ch model support max 8ch 1080P video input,8 ch audio input;
- 8-36V wide voltage with low power consumption;
- Unique UPS Technology ensures the integrality of record when power failure occurs, even can for 8-10s;
- Exclusive pre-allocate File System protect data completeness,prevent HDD & SD Card fragment,ensure date stablely and completely;
- Built in G-sensor module for optional;
- Built in GPS/BD Extension module for optional;
- 3G/4G, GPS, Wi-Fi function for optional and switch automaticly;
- Central management software provided for optional;
- Local and remote PTZ control;
- Data redundant storage technology;
- Remote control ,remote download,remote playback;
- Support 6ch I/O alrm,over speed alarm,g-sensor alarm,video lose alarm, motion detection alarm;
- support USB port data backup and device update;
- HDD+SD Card Storage ( Support 2.5" HDD, max 128G SD Card);
- Support HDD heating functions,can work in harsh environment;
- Realize real time monitor through 3G/4G/wifi;
- Support Broadcast/Intercom/Text sent etc;
- Can help customer to add oil sensor/temperature sensor / POS / LED Advertisement Panel for optional;
- Support IOS/Android Phone Remote monitor
Bus, School bus, Logistics vehicle, Taxi, Police car, Special purpose vehicle, Train/metro, Ship/boat | ITEM | DESCRIPTION |
| System | Linux |
| GUI | Setup system parameters through the remote controller. |
| Language | Chinese/English/Customized |
| Security | Administrator and user password supported |
| Video and preview | Video input/output | 8 channel input; 2 channel output; 1.0Vp-p, 75Ω |
| OSD | Overlays letters… like date & time information and vehicle ID into video streaming |
| Video Compression Criteria | H.264.With Hisilicon technology |
| Preview |
Support 1 ch 2ch 4ch 6ch 8ch preview. |
FPS | PAL: 25Frame/s NTSC:30Frame/s |
| Resolution | Support 1080p,720P,D1 for optinal |
| Video quality | 1-8 levels, 1 is the highest level and 8 is the lowest level |
| Video Bit Rate | D1: 800Kbps ~ 2Mbps, 8 quality level support,
720P:1Mbps-4Mbps, 8 quality level support
1080P:2Mbps-8Mbps, 8 quality level support |
Audio | Audio input/output | 4 channel input for 4ch model / 8ch for 8ch model; 1 channel output |
| Audio Streaming | G.726 |
Record | Storage | SD card: support max 128G,
HDD: support 2.5 inch HDD
support USB for data export |
| File form/system | H.264/FAT32 |
| Recording Mode | Default auto recording after power on, support timed recording, alarm recording. |
| Video Search | Search video by time, type (normal or alarm), target SD card |
| Video playback | Support 1 to 4/8 channels playback simultaneously |
| Support forward and backward at the speed of: x2, x4, x8, x16,x32, x64. |
| Alarm | Alarm input | Support up to 6 channels alarm input |
| Alarm record | include the recording within 15 seconds ahead of the alarm starting, and the recording after alarm dynamically adjusted |
| Alarm of storage | Support storage alarm |
| Alarm function | The alarm of video loss |
| Communication interface | RS232, RS485,RJ45 10M/100M self-adaption Ethernet interface |
| Wireless transmission (optional) | Built-in 3/4G wireless transmission module for optional, WCDMA, CDMA2000, TD-SCDMA,TDDLTE,FDDLTE system optional; Compatible with GPRS, EDGE;
Built-in Wi-Fi module for optional; |
| GPS (optional) | Support external GPS module for optional |
| Data remote transmission | Support 3G/4G/Wi-Fi transmission, Wi-Fi priority transmission strategy, remote download; |
| PTZ control | Support PTZ control function by local remote controller or client software; |
| Parameter configuration | Support parameter configuration |
| G-sensor (optional) | Built-in G-sensor moudule for optional |
| Upgrade | Upgrade by SD card or USB (advise USB) |
| Power&consumption | Power management |
1.ACC ON/OFF
2. System power off according to the delay time
3.Timing ON/OFF
With overload protection, undervoltage protection, short protection, |
| Power input | DC:+8V ~ +36V |
| Power output | +12V@5*0.5A; |
| Power consumption | The normal state<10W;Standby 0W |
| Working environment | Operating temperature | -25ºC ~ +60ºC |
| Operating Humidity | 10% to 95% |
| Dimensions | 142(W) x62(H) x123(D) mm. |
| Weight | 1.2-1.8KG |
| Prod Model: |
VC-H3-8 |
| Compression Format: |
H.264 |
| Interface: |
Aviation +VGA+RCA |
| Interface Display: |
1CH 2CH 4CH 6CH 8CH Preview. |
| Brand: |
Vcomsky |
