4.3 Inch Color TFT LCD Car Monitor System

Name: 4.3 Inch Color TFT LCD Car Monitor System
Brand: ibuyautoparts.com
SKU: 753865465
Availability: InStock
Rating: 4.8 (136 reviews)

Price:	US $ 55/Set
Trade Terms:	FOB,EXW
Min Order:	1/Set
Pay Type:	T/T,Paypal

Contact Supplier

Showroom Product Company Profile

4.3 Inch Color TFT LCD Parking Car Monitor /Car Rearview Camera
Monitor:
Screen size: 4.3" digital TFT-LCD
Display format: 480 x RGBx 272 Dot
System: PAL/NTSC
One video input
Brightness: 300cd/m2
Operation temperatures: -20°~70°
Temperature range storage range -30-80°
Power consumption: 2W
Power requirement: DC 12V

Camera Specification:
- Image Device: 1/4" CMOS image sensor
- TV System: NTSC/PAL
- View Angle: 170°
- Waterproof: IP68
- Vibration Rate: 10G
- Resolution: 420TV lines
- 1.8mm waterproof lens
- Effective Pixels: 510*496pixels
- Sensing Area: 5.961mm*4.276mm
- Minimum Illumination: 0-01Lux
- Video Output: 1-0vp-p, 75Ohm
- Gamma Consumption: 0-45
- White Balance: Auto
- S/N Ratio: Better than 48dB
- Electronic Shutter: 1/60S-1/5000S
- Power Supply: DC12V
- Operating Temperature: -20° to +70° (RH95%Max.)
- Storage Temperature (Deg.C): -30~+80°(RH95%MAX.)

Aluminum Shell Backup Waterproof Camera

Image Type: 1/3 Inch Color CCD

Horizontal Resolution:720TV Lines

NTSC:976(H)×494(V) PAL:976(H)x582(V)

Usable Illumination : 0Lux ( Built in 10 IR LED's for Picture Support in the Dark)

Free viewing angle: 130°

Waterproof: 100% Waterproof IP69K Rating

Shockproof: 10G

Video Output:1.0Vp-p75Ω

Operating temperature: -40ºC to +70ºC (Automatic heating when the camera's running temperature is below 10ºC optional)

Power supply:DC12V (from Reversing Monitor)

Dimensions: 75(W) x 43(H) x 38(D) mm (without mounting)

Weight Approx: 179g

Prod Model:	MNC09&TM4301
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Screen Size:	4.3 Inch
Display Format:	480 X Rgbx 272 DOT
System:	PAL/NTSC
Brightness:	300CD/M2
Image Device:	1/4inch CMOS Image Sensor
Waterproof:	IP68
Interface:	RCA
Definition:	420TVL
Chip:	CMOS
Waterproof Grade:	IP68
