18.5kw Mechanical Diesel Injection Pump Test Bench /Diesel Pump Test Bench

Name: 18.5kw Mechanical Diesel Injection Pump Test Bench /Diesel Pump Test Bench
Brand: ibuyautoparts.com
SKU: 814262495
Availability: InStock
Rating: 4.5 (48 reviews)

Price:	Negotiableset
Min Order:	1set
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Common Rail Injector Test Bench
Model:12PSB

Introduction
12PSB series diesel fuel injection test bench is design for customer's require.This series test bench adopt high quality frequency conversing device, and it has characteristic with hi-reliability,ultra-low-noise, energy save, high output torque, perfect auto-protecting function and operate easy. It is the kind of product with high quality and good price in our business.

Function
1.Measurement of each cylinder delivery at any speed.
2.Test point and interval angle of oil supply of injection pump.
3.Checking and adjusting the mechanical governor.
4.Checking and adjusting the distributor pump.
5.Experiment and adjusting of behavior of supercharging and compensatory.
6.Measurement of oil return of distributor pump.
7.Testing of the electromagnetic value of distributor pump.(12V/24V)
8.Measurement of the internal pressure of distributor pump.
9.Checking of the advance angle of advance device.
10.Checking the sealing of injection pump body.
11.Install auto-sucking oil tube to check oil supply pump(including VE pump)

TECHNICAL PARAMETER
1. Main motor output power(kw):18
2. Stroke Counting (Rpm):0-4000
3. Standard injectors:ZS12SJ1
4. Ten speed preset
5.With 12v/24v DC power
6.digital display of oil count times
7.digital display of temperature
8.with air supply
9.Measurement of oil return of distributing pumps
10.VE
11.Measure oil flux of VE pumps
12.Measure the internal pressure of VE pump
13: Dimension of Packing ( L*W*H(m)):2.30*1.10*1.70
14: Gross weight of Test bench(kg):800

Prod Model:	BFC
Testing Injector:	Bosch, Siemens, Delphi, Denso
Testing Range:	Common Rail Diesel Injector
Motor Output Power:	18kw
Voltage:	380V, 3 Phase 50/60Hz
Number Of Cylinders:	12
Stroke Counting:	0-4000rpm
Low Pressure Of Fuel Oil Pressure:	0~4bar
High Pressure Of Fuel Oil Pressure:	0-40bar
Volume Of Fuel Tank:	40L
Certification:	CE
Update Method:	by Email
