Xinder Wheelchair Topper Load 23kg for Wheelchair User

Name: Xinder Wheelchair Topper Load 23kg for Wheelchair User
Brand: ibuyautoparts.com
SKU: 771293315
Availability: InStock
Rating: 5 (137 reviews)

Price:	US $ 11111111111111/Piece
Trade Terms:	FOB,EXW
Min Order:	1/Piece
Pay Type:	L/C,T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

WCT Wheelchair Topper
INTRODUCTION:
WCT wheelchair topper is installed on roof of car, van and minivan. It is used to store foldable wheelchair.
This wheelchair topper can be operated by wheelchair user. It is controlled by remote control to take wheelchair in/out of equipment.
The drive mode for this topper is motor and chain. Meanwhile, it can be operated manually for emergency.
We have turning seat which is suggested to use together with this topper, in which way the wheelchair user can operate the topper by himself and more easier.
Functions:
Store wheelchair on car roof automatically when wheelchair is not needed
Application:
Mainly used for handicapped car which driven by the disabled themselves
Installation Requirements:
Height from ground is 1016mm. Keep this equipment working horizontally during extending and stowing. Distance between front window is at least 254mm.
Working time for one cycle is 75-85s

Technical Specifications

Model	Dimension LWH mm	Distance after box opened	Own Weight	Weight of wheelchair	Working time for one cycle	operation	Volt
WCT	13801290540	930mm	56Kg	≤20.5Kg	75-85 S	Remote Control	12-24V

Prod Model:	WCT
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Dimension:	13801290540mm (LWH)
Wheelchair Required:	Foldable Wheelchair
Working Time:	75-85 Seconds
Own Weight:	56 Kg
Operation:	Remote Control
Working Voltage:	12 V
Packing Size:	14501350600 mm
Material:	Steel
Opening:	Single Side
Brand:	Xinder

Located in Changzhou New North District, Xinder-Tech Electronics (original Xinder Electronics) specializes in designing, manufacturing and selling wheelchair ramps, wheelchair lifts, electric step, manual step, wheelchair restraint system, seat fixing system, manual driving system, electronic accelerator pedal and other disabled products.

Xinder-Tech is the leader company of this line in China, and our products have taken up 90% of inner market. Meanwhile, our products has been exported to may countries, such as France, Italy, New Zealand, Finland, Brazil, Poland, Costa Rica, Korea, Australia, Malaysia, Bulgaria, Turkey, Israel, Philippines, Iran, India, South Africa and so on. Service includes R&D of product, manufacture, system debugging, on-site field visit to customer. Main engineers occupy 40% of staffs, with good experience, and they have been professionally and systemically trained in America, Italy, Malaysia and Brazil.

There are over 3000 ramps used for the Beijing Olympics, over 700 ramps exported to Korea. 100 PCS of WL-UVL wheelchair lift, about 500 PCS of electric wheelchair ramp and more than 1000 sets of wheelchair tie down system to Guangzhou Asia Game.

Our goal is to provide the best solutions for customer's requirements.

Xinder-Tech is an ISO 9001: 2016 compliant company. Our WL-D series wheelchair lift, WL-UVL series wheelchair lift, WL-T series wheelchair lift and ES Series electric step have got CE certificate, and EWR series wheelchair ramp has passed the EMC test, wheelchair tie down system has passed test of ISO 10542-2.

XINDER works in many fields:

1 Electric & Manual Wheelchair Ramp

2 Wheelchair Lift

3 ES Series Electric Step

4 Manual Step

5 Wheelchair Restraint System

6 Manual Control System

7 Electronic Accelerator Pedal

8 Handicapped Electric car

9 Seat Fixing System
