MIG Welding Machine/Semi-Automatic MIG Gas Shielded Welder

Name: MIG Welding Machine/Semi-Automatic MIG Gas Shielded Welder
Brand: ibuyautoparts.com
SKU: 812550115
Availability: InStock
Rating: 4.9 (111 reviews)

Price:	US $ 1-2/Piece
Min Order:	1/Piece
Pay Type:	T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Semi-automatic MIG gas shielded welder

Description:
MIG semi-automatic gas shielded welding machines are suitable for all position and highspeed welding of sheet metal and medium plate.Mainly used in welding of ferrous metallic materials such as low carbon steel,low alloy steel, high strength low alloy steels,stainless steels,steels, iron,aluminum and nickel,etc.With one piece design, Pulse Width Modulation(PWM) electronic speed control provides a high efficiency of wire feeding and a smooth and steady of wire feed speed during welding process.Adjustable welding and intermittent time is specifically designed for spot welding of sheet metal, easily and flesibly.Extensively used in the welding and field operation of steel construction,oil pipeline,car production,shipyard,industrial installation,etc.

Features

1. Voltage auto-detect function

2. Welding gun testing function

3. Digital display

4. Multi-bridge rectifier

5. Wire feeder with four-roll dual drive system

6. Complete with heated regulator

7. Adjustable dynamic characteristic of arc

8. Good forming capability and quality weld appearance

9. Complete with tool box and anti-blocking agent

10. Separated wire feeder and welding gun with lengthen cable is available for option

Specifications:

Input Voltage	AC380-400V 3-phase
Frequency	50/60Hz
Rated maximum supply current	30A
Maximum effective supply current	23.4A
Output current /voltage	35A/17V-500A/39V
No-load voltage	21-46A
Welding current range	35-500A
Duty cycle	35%
Insulation grade	F
Insulation grade	Low carbon Steel Solid wire
Weldable wire	0.8,1.0,1.2mm
Type	All-in-one
Voltage regulation range	10steps
Dimensions	880470890mm
Weight	108kg

Prod Model:	FY-5500/2E
Demension:	880 X 470 X 890mm
Weight:	110kg
Voltage:	AC380-400V 3-Phase 50/60Hz
Certification:	ISO9001:2000
Usage:	MIG Torch
After-Sales Service Provided:	Overseas Service Center Available
Welding Capacity: Weldable Wire:	0.8,1.0,1.2mm
Power:	30kw
