Intelligent Motor Starter Single Phase AC220V (S521)

Name: Intelligent Motor Starter Single Phase AC220V (S521)
Brand: ibuyautoparts.com
SKU: 708344942
Availability: InStock
Rating: 4.6 (127 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB
Min Order:	50/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

1.Product Information
SINGLE PUMP CONTROL PANEL
MODEL: S521

Model	S521
Main technical data
.Start type	Direct on line
. Qty of controlled pump	Single pump
. Rated input voltage:	AC220V-240V Single phase 50HZ/ 60HZ
. Rated output power:	0.37kw-2.2kw (0.5hp-3hp)
.Capacitor:	Reserved space for installing start capacitor
Product function	Over load protection Pump stalled protection Dry run protection with sensor free Under voltage protection Over voltage protection
Application & Control characteristic	Control and protect universal pump Using water level sensor or float switch to control pump start and stop Applied for water supply by liquid level control through float switch or liquid probe Applied for water supply by pressure control through pressure switch and pressure tank Applied for drainage by liquid level control through float switch or liquid probe
Other features	Push button calibration Memory function when power off & recovery
Main installation data
Working temperature Working humidity Degree of protection Install position Unit dimension (L x W x H)	-25ºC-- +55ºC 20%--90%RH, no drips concreted IP22 Wall mounting 170× 155× 85mm

2.Company Information

1)Brief introduction: as the supplier of pump control panel and control accessories, major products including: Intelligent Single / Dual Pump Control Panel, Motor Protector / Starter , Reverse Osmosis Controller, Anti-Clogging Reversal Pump Control Panel
More information, please visit: www.leading-china.com

2)Our location and communication
From Guangzhou to Changsha takes 1hour by air, 2.5hour by high speed train
From Shanghai to Changsha takes 1.5hour by air, 5hour by high speed train
From Beijing to Changsha takes 2.5hour by air
From Hong Kong to Changsha takes 2hour by air

Prod Model:	S521
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Input Voltage:	AC220V
Phase:	Single Phase
Kind Of Packing:	Paper Carton

Hunan Leading Science & Technology Development Co., Ltd is the professional manufacturer of intelligent pump control system applied for monitoring and protecting of pumps in home and industry use;

Leading Science & Technology has always been a leader in the production, research & development of intelligent pump control system and relative pump control products. Million of our prime products have been sold on the market for stable quality and reasonable price.

Leading Science & Technology has established stable relations with many pump producers and distributors from China and overseas.

Till now, Leading Science & Technology we have passed CE, ISO9001: 2008 certificate.
