Deep groove ball bearing B8-74 8X22X11 auto bearings
Quick Details
Structure: |
Deep Groove |
Type: |
Ball |
Brand Name: |
YD |
Precision Rating: |
P0, P6, |
Seals Type: |
Open, 2RS, ZZ |
Number of Row: |
Single Row |
Place of Origin: |
China (Mainland) |
Material |
Chrome/stainless steel |
Clearance of RLS6: |
C0, C2, C3 |
Vibration: |
Z1V1, Z2V2, |
Service |
YD brand or OEM Service | |
|
Sample: |
available |
Supply |
stock, large production capability | |
|
Payment terms: |
T/T, western union, paypal |
Delivery |
by sea or air, express |
Specifications:
1.Wide range of use
2.Delivery in time
3.Factory price
4.High qualit
Packaging & Delivery:
Packaging Detail: Standard packaging carton packaging OEM service
Delivery Detail: 5-15days
Application of inch size ball bearings:
-inch size ball bearings are deep groove ball bearing with very small sizes.
-inch size ball bearings are widely used in home appliances, reel fishing, etc.
| 19BSW07 | 19x32x7 | | B25-83 | 25x58x16 |
| 32TM12 | 32x84x15 | B27-12B | 27x82x19 |
| 40TM11 | 40x90x19 | B27Z-8 | 27.8x78.5x15 |
| 40TM18VZ | 48x80x16 | B28-30 | 28X78X20 |
| 60TM04N | 60x101x17 | B28-31 | 28X72X17 |
| 65TM02A | 65x100x17 | B28-34 | 28X75X19 |
| B28-31 | 28x72x17 | B29-11N | 29X78X16.5/19 |
| B29-11 | 29x78x18 | B29-2NX | 29x80x18/20 |
| B31-15 | 31x72x9 | B30-120 | 30x80x21 |
| B31-16N | 31x80x16 | B30-126 | 30x75x20 |
| B31-26N | 31x93x21 | B31-1 | 31x60x17 |
| B31-26N | 31x80x16.5 | B31-10 | 31x80x16 |
| B32-33 | 32x72x15 | B31-13 | 31x93x19 |
| B32Z-6 | 32.5x76x11 | B31-15 | 31x72x9 |
| B35-200 | 35X55X9 | B31-16A1N | 31x80x16 |
| B35Z-7 | 35.5x95x12 | B31-16N | 31x80x16 |
| B37-10 | 37x88x18 | B31-23N | 31X94X21 |
| B37-9N | 37x85x13 | B31-28N | 31x80x16.5 |
| B43-3 | 43x73x12 | B32-10 | 32x72x19 |
| B43-4 | 43x87x19.5 | B32-10/S | 32x72x19 |
| B45-106N | 45x90x17 | B32-14NR | 32x80x20 |
| B45-111E | 45x105x21 | B32-18NR | 32x80x23 |
| B45-90 | 45x100x17.9/21 | B32-33 | 32x72x15 |
| B49-5 | 49x95x18 | B32-34 | 32x80x10 |
| B49-7 | 49x87x14 | B32Z-6 | 32.5x76x11 |
| B57Z-8 | 57.5x80x14 | B34Z-5E1 | 34.288X62X14 |
| B60-57 | 60x101x17.2 | B33Z-12 | 33.5X76X11 |
| B67-1 | 67x92x13 | B35-200 | 35X55X9 |
| B67Z-7 | 57.5x80x12/13 | B35-221 | 35X72X15 |
| DG328012 | 32.5x80x11.5 | B35-27 | 35.5x95x12 |
| DG4880 | 48x80x16 | B35Z-7 | 35.5x95x12 |
| B40-121 | 40x72x14 | B36Z-10 | 36X67X29 |
| B17-123 | 17x52x21 | B37-10 | 37X88x18 |
| B17-126D | 17x62x17.5 | B37-9N | 37X85x13 |
| B17-127D | 17x62x20 | B37Z-1 | 37.8X68X18 |
| B17-136 | 17x35x10 | B39-5 | 39X86X20 |
| B17-29 | 17x52x22 | B40-121 | 40X72X14 |
| B17-47D | 17x47x24 | B40-123 | 40X123.2X32 |
| B17-96 | 17x47x18 | B40-134N | 40X100X25 |
| B18Z-1B1 | 18.7x38x10 | B40-167A | 40X90X19 |
| B20-112 | 20x47x14 | B43-1 | 43X80X17 |
| B20-122 | 20x47x16 | B43-2 | 43X80X17 |
| B20-141 | 20x62x16 | B43-8 | 43X87X19.5 |
| B20-151 | 20x52x16 | B45-108 | 45X90x17 |
| B20-160 | 20x52x12 | B45-130NX2UR | 45X85X15 |
| B20-161 | 20x52x14 | B49-3 | 49X90X19.7 |
| B20-49NR | 20x55x15 | B57Z-7 | 57.7X80X13 |
| B22-19 | 22x62x17 | B58-1 | 58X104/108X21 |
| B23-9 | 23x42x7 | B60-44 | 60X130X22/31 |
| B24Z-2URN | 25x63x17 | B60-57N | 60x101x17.2 |
| B25-109 | 25x52x15 | B67-1 | 67X92x13 |
| B25-10BC3 | 25x65x17 | B67Z-7 | 67.5X80X12/13 |
| B25-139 | 25x68x18 | B75-55NX | 75X110X18 |
| B25-145 | 25x63x17 | B8-75ZZ | 8X24X10/9 |
| B25-147 | 25x62x19 | BD22-2ENX1 | 22X47X20.6 |
| B25-157 | 25x68x18 | BD25-9 | 25X52X23.5 |
| B25-163 | 25x60x19/27 | B8-74 | 8X22X11 |
| B25-164ZNXC3 | 25x60x17/25 | BD17-29 | 17X52X22 |
| B25-166 | 25x67x26 | BD25-49NX | 25X60X27 |
| B25-185V | 25x61x20 | BD29-2B | 29X55X22.5 |
| B25-19 | 25x63x18 | BD35-12B | 35X64X37 |
| B25-198 | 25x63x18 | BD35-15 | 35X65X26 |
| B25-214 | 25X62X16 | BDZ27-1AUR | 27X63X23 |
| B25-224 | 25X62X16 | BDZ27-2NX | 27X60X27 |
| B25-238 | 25X68X19 | BDZ27-3N | 27X63X28 |
| B25-238NX | 25x68x19 | BDZ38-1 | 38X68X26 |
NUMBER | Boundary dimensions (mm) | NUMBER | Boundary dimensions (mm) |
| d | D | B | d | D | B |
| RLS 4 | 12.7 | 33.34 | 9.525 | RMS 4 | 127.7 | 41.28 | 15.88 |
| RLS 5 | 15.875 | 39.69 | 11.11 | RMS 5 | 15.875 | 46.04 | 15.88 |
| RLS 6 | 19.05 | 47.63 | 14.29 | RMS 6 | 19.05 | 50.8 | 17.46 |
| RLS 7 | 22.225 | 50.8 | 14.23 | RMS 7 | 22.225 | 57.15 | 17.46 |
| RLS 8 | 25.4 | 57.15 | 15.88 | RMS 8 | 25.4 | 63.5 | 19.05 |
| RLS 9 | 28.575 | 63.5 | 15.88 | RMS 9 | 28.575 | 71.44 | 20.64 |
| RLS 10 | 31.75 | 69.85 | 17.46 | RMS 10 | 31.75 | 79.37 | 22.23 |
| RLS 11 | 34.925 | 76.2 | 17.46 | RMS 11 | 34.925 | 88.9 | 22.23 |
| RLS 12 | 38.1 | 82.55 | 19.05 | RMS 12 | 38.1 | 95.25 | 23.81 |
| RLS 13 | 41.275 | 88.9 | 19.05 | RMS 13 | 41.275 | 101.6 | 23.81 |
| RLS 14 | 44.45 | 95.25 | 20.64 | RMS 14 | 44.45 | 108 | 26.99 |
| RLS 15 | 47.625 | 101.6 | 20.64 | RMS 15 | 47.625 | 114.3 | 26.99 |
| RLS 16 | 50.8 | 101.6 | 20.64 | RMS 16 | 50.8 | 114.3 | 26.99 |
| RLS 18 | 57.15 | 114.3 | 22.23 | RMS 18 | 57.15 | 127 | 31.75 |
| RLS 20 | 63.5 | 127 | 23.81 | RMS 20 | 63.5 | 139.7 | 31.75 |
Bearing No. reference:
Magneto ball bearings |
| | | Size | FED | HOF | HYA/ND | NDP | TOR | RAM | RHP | RIV |
| E4 | EN4 | 4 | 16 | 5 | | | | ND5-4 | | | | N4 |
| E5 | EN5 | 5 | 16 | 5 | FB5 | | ND5 | ND5 | T5 | | EN5 | N5 |
| E6 | EN6 | 6 | 21 | 7 | | A6 | ND6 | | T6 | M6 | EN6 | N6 |
| E7 | EN7 | 7 | 22 | 7 | | A7 | ND7 | | T7 | | EN7 | N7 |
| E8 | EN8 | 8 | 24 | 7 | FB8 | A8 | ND8 | ND8 | T8 | M8 | EN8 | N8 |
| E9 | EN9 | 9 | 28 | 8 | FB9 | A9 | ND9 | ND10-9 | T9 | M9 | EN9 | N9 |
| E10 | EN10 | 10 | 28 | 8 | FB10 | A10 | ND10 | ND10 | T10 | M10 | EN10 | N10 |
| E11 | EN11 | 11 | 32 | 7 | FB11 | A11 | ND11 | ND11 | T11 | M11 | EN11 | N11 |
| E12 | EN12 | 12 | 32 | 7 | FB12 | A12 | ND12 | ND12 | T12 | M12 | EN12 | N12 |
| E13 | EN13 | 13 | 30 | 7 | FB13 | A13 | ND13 | ND13 | T13 | M13 | EN13 | N13 |
| E14 | EN14 | 14 | 35 | 8 | FB14 | | ND14 | | | M14 | EN14 | N14 |
| E15 | EN15 | 15 | 35 | 8 | FB15 | A15 | ND15 | ND15 | T15 | M15 | EN15 | N15 |
| N3048 | - | 15 | 37 | 8 | | | | | | | | |
| BO15 | - | 15 | 40 | 10 | | | | | | | | |
| E16 | EN16 | 16 | 38 | 10 | FB16 | A16 | ND16 | | | M16 | EN16 | N16 |
| L17 | - | 17 | 40 | 10 | FBL17 | | ND17H | | | | | 7828 |
| E17 | EN17 | 17 | 44 | 11 | FB17 | | ND17 | ND17 | T17 | M17 | EN17 | N17 |
| BO17 | - | 17 | 44 | 11 | FB17 | | ND17 | ND17 | T17 | M17 | EN17 | N17 |
| M17 | - | 17 | 44 | 10 | | | | ND17E | | | | |
| E18 | EN18 | 18 | 40 | 9 | | | ND18 | | | | EN18 | N18 |
| E19 | EN19 | 19 | 40 | 9 | | | ND19 | | T19 | | EN19 | N19 |
| E20 | EN20 | 20 | 47 | 12 | | | ND20 | ND20 | | | EN20 | N20 |
| L20 | - | 20 | 47 | 14 | | | | | | | | |
| M20 | - | 20 | 52 | 15 | | | | | | | | |
| L25 | - | 25 | 52 | 15 | | | | | | | | |
| M25 | - | 25 | 62 | 17 | | | | | | | | |
| L30 | - | 30 | 62 | 16 | | | | | | | | |
| M30 | - | 30 | 72 | 19 | | | | | | | |
|
Zaozhuang Yiding Bearing Co., Ltd. is specialized in bearing, Oil seals export, production, selling and after-service. In practice for many years, we established strict quality assurance system.
Our products range covers Deep Groove Ball Bearings, Cylindrical Roller Bearings, Needle Roller Bearings, Tapered Roller Bearings, Thrust Ball Bearings, Thrust Cylindrical Roller Bearings, Angular Contact Ball Bearings (single row & double row), Linear bearing, Plain shaft(Axis ) series, Linear guide bearing, Rod end bearing, Joint bearing, Radial bearing and Beeline Bearings. They are widely used in applications like including Agriculture, Automotive, Steel industry, Pumps & Compressors, Railways, Mining &Construction, Motorcycles, Electric Motors, Printing and Power Tools, etc.
Our principle is service and quality First! By ceaselessly improve our quality and after-sale service, our products win high praise for our favorable price, excellent service and timely delivery. No matter before or after sales, from quality to price, we have the complete and professional management system. Welcome inquiry by phones or emails. We will sincerely serve you!
