AA4c Vertical Boring Machine T7220b

Name: AA4c Vertical Boring Machine T7220b
Brand: ibuyautoparts.com
SKU: 737878535
Availability: InStock
Rating: 4.6 (23 reviews)

Price:	US $ 12000-13000/Piece
Trade Terms:	FOB
Min Order:	1/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Features

The T7220B vertical boring machine is mainly used to bore high accurate holes of cylinder body and engine sleeve and other accurate holes. The T7220C is mainly used for fine boring high accurate holes of cylinder body and engine sleeve also for other accurate holes, it's can used for milling surface of cylinder. The machine can be used to boring, milling, drilling, reaming.

Model T7220B T7220C
Max. Boring diameter Φ 200 mm Φ 200 mm Max. Boring depth 500 mm 500 mm
Milling cutter head diamenter - 250 mm Max. Milling area (L× W) - 850× 250 mm
Spindle speed range 53-840 r/min
Spindle feed range 0.05-0.20 mm/r
Spindle travel 710mm
Distance from spindle axis to carriage vertical plane 315mm
Table longitudinal travel 900mm 1100 mm
Table longitudinal feed speed - 54, 108 mm/min
Table longitudinal quick move speed - 1500 mm/min
Table latitudinal travel 100 mm
Boring dimension accuracy IT7

Prod Model:	T7220B
Certification:	CE
Type:	Vertical Boring Machine
Brand:	AA4c
Design:	Vertical

Shanghai AA4C AUTO Maintenance Equipment Co., Ltd is professional auto maintenance equip ment manufacture since 1995. AA4C means Always and All for(4) Customer. Our factory covers an area of more than 20, 000 squares meters and with our up-today manufacturing facilities, high-tech industrial, product developing manufacturing sales and perfect after-service with a total capital of more than ten millions. For many years our company has been awarded as "Enterprise with High Reputation" "Enterprise with High Credit in Quality " and "China National Grade AAA Enterprise, etc. Besides, Wehave passed ISO9001, authenticated by 2000 International Quality Control System.

Tire changers, Wheel balancers, car lifts are the goods produced by ourself, other goods are supplied by our cooperated factories in order to decrease customers' trouble to buy many goods from many factories. We are mainly dealing AA4C products development, product design as well as OEM/ODM manufa-cturing...Our Product has been shipped to worldwide (Europe, East Europe, North & South America, Africa, Australia, Middle East, Asia as well as different province in China).

Facing the future opportunites and challenges, AA4C will be still adhering to "Seeking higher & being practical" trying to enlarge the intercourses and cooperation with other producers in the fieid both at home and aboad; And exert ourselves to pay back our clients with high-quality products and perfectafter-service. Our goal is: Always and All for(4) Customer.
