2018 Hot Sale APP Bluetooth tire pressure monitoring system for smart phones

"APP Bluetooth tire pressure monitoring system" is a TPMS designed specifically for smart phones to display tire Pressure data via APP,and transfer signs through Bluetooth. The Bluetooth sensor transfer the pressure and temperature data of car tires during the vehicle driving process. The tire pressure and temperature data are displayed and monitored, and if the data is abnormal, the APP system will alarm timely to ensure traffic safety.

Internal Sensor:
Processor:8 bits MOU/SO8, Core: ARMMO
Working Voltage: 3V
Working Current: 540uA, Sleep current:2.4uA
Bluetooth working frequency:2.4GHz, Bluetooth transmission power: 0dBmMAX
Display mode: App mode, Response time: ≤6s
Waterproof degree:IP67, Working humidity: 95%MAX
Tire pressure range:100-900kpa
Accuracy of tire pressure:±0.1Bar
Working temperature:-40ºC~+120ºC
Storage temperature:-45ºC~+125ºC
Battery capacity: 140mAh
Battery life:5 Years(Caculating based on 4 hours of dring a day)
Weight: 30g±1g

Sensor Parameter

*Parameter*	Value	*Parameter*	Value
Weight	30.0g	Dimension	70mm53mm20mm
Black Operating Current	< 3 mA	Bright operating current	< 5 0 mA
RF Signal reception sensitivity	- 90 dbm	Operating Voltage	3 V
RF Transmission frequency	433 . 92 MHz±50 KHz	IP	IP67
Storage temperature	- 45ºC~ 125ºC	Operating temperature	-40ºC--80ºC
Battery Life	5 Years	Battery capacity	140mAh
Transmit power	<10dBm	Pressure accuracy	±1.5Psi

Packaging Details: Gift Box Size:200*185*70MM

Delivery Details: 3-7 days for sample and 15-20 business dyas for general order

Our Services:
1.Professional and 17 years history
2.17-year overseas marketing &17-year OEM/ODM experience
3.100% quality test before shipment
4.Market leading prices
5.Best after-sales service
6.Abundant exporting experience

Notice: For more detail information,please feel free to contact us!

Prod Model:	BleApp1-E-v
Waterproof Degree:	IP67
Battery Life:	5 Years
Weight:	30g
Storage Temperature:	-45~125 °c
Working Temperature:	-40~120 °c
Temperature Accuracy:	±2°c
Working Voltage:	3 V
Working Pressure:	0~99 Psi
Pressure Accuracy:	±1.5psi
Transmit Frequency:	433.92 MHz
Certification:	E-MARK, FCC
Update Method:	by Hard Disk
Testing Equipment Type:	Bluetooth TPMS

Established in 2001, Shenzhen Sunway Industry Co., Ltd. Is a professional manufacturer in car electronics industry, such as TPMS, DVR. Parking Sensor, Car Camera, Headrest, Monitor, DTV Receiver Box.

With Industrial Zone in Hunan Province, headquarter in Shenzhen, and up to 300 employees, Sunway's monthly output is 800, 000 pieces with current export of 80% of all products. We export to over 80 countries and regions, especially USA, EU, Russia, Australia, Mexico, Brazil, etc.

We have a skilled R&D team and be able to process OEM/ODM orders. We provide products with high quality, shortest delivery time, competitive price and more professional service. We test every piece of raw material from our suppliers and every finished product will be tested at least 3 times before shipment, all those make us become a professional supermarket supplier, such as USA Wal-mart.

As an ISO9001 certified company and TS 16949 factory, with CE, E-MARK, RoHS approval, we always try our best to satisfy our clients and strengthen our position in the global market.
