16m X 5.5m X 5m Truck Painting Room
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union |
| Prod Model: |
PC-LSB |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Warranty Time: |
2 Years |
| Service Time: |
Lifelong Maintenance |
| Color: |
White or Blue |
| Voltage Requires: |
380V/3p, 220V/3p Or220V/1p |
| Paint Mist Treatment: |
Dry-type |
| Heating Mode: |
Diesel |
| Airflow Direction: |
Fully Undershot-type |
| Certification: |
CE |
| Condition: |
New |
| Type: |
Large Spray Booth |
Product Description
Paintcolor Spray Booth Bus Painting Booth 16m X 5.5m X 5mAny booth size request can be met!!!Paintcolor company quantifies the production of standard spray booth; at the same time, "one-to-one" service is our important and special sale method and service. For different countries and the special requirements of different customers, we make the design and produce the booth based on the size of the site, the workpiece, the type of paint and the budget level. It really 100% stands on your point to solve all the problems. Paintcolor is the one specialty spray booth manufacturer you can not miss.
Specification| technical parameter | Outside Dimeision(L×W×H) | 16150×7400×5800 | structure parameter | Panel Thickness(mm) | 75 |
| Inside Dimension(L×W×H) | 16000×5500×5000 | Steel thickness for the panel(mm) | 0.5 |
| Door Access Width(mm) | 4500 | panel insulated material | EPS |
| Door Access Height(mm) | 4500 | Grid | 30*4flat steel |
| Loaded air speed(m/s) | ≥0.25 | framework for booth | spuare tube+angle iron |
| noise(dB) | ≤85 | support mesh material | square steel |
| Total Power(KW) | 49 | the ventilation cabin material | square steel tube+galvanized plate |
| Max Temperature(ºC) | 80 | illumunation parameter | lamp quantity | Ceiling Lamps72 |
| burner parameter | Burner origine and model | Italy
BT34 | Side lamps 44 |
| most quantity of heat(kcal/h) | 340000 | Power/set(W) | 36 |
| oil consumption(kg/h/set) | 18-33 | brand of the lamp | philips |
| heat energe converter material | stainless steel | Illumunation(Lux) | ≥800 |
| air-inlet technical parameter | Air-inlet fan model | YDW-5.6S | air-out let parameter | chimney diameter | 900×900 |
| rating blower capability(m3/h) | 17530 | chimney material | galvanized plate |
| power/set(KW) | 5.5 | chimney quantity | 12 meters tube,
2elbow |
| quantity | 4 | electrical parameter | control box | CE |
| air-outlet technical parameter | Fan model | 4-82-6.3E | components |
| rating blower capability(m3/h) | 34000 | others | colour | sea blue/orange/hoariness |
| power/set(KW) | 11 | Voltage | 380V/3PH/50Hz |
| quantity | 2 |
