| Prod Model: |
WLD9000 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model: |
Wld-9000 |
| External Size: |
7000X5450X3480(Mm) |
| Internal Size: |
6900X3900X2800(Mm) |
| Main Door Size: |
3000X2750(Mm) |
| Air Flow: |
25000(M3/H) |
| Air Speed: |
0.3-0.5m/S |
| Fuel Consumption: |
5-6kg/Vehicle |
| Total Power: |
15kw |
| Vehicle Suited: |
Saloon Car/Jeep/SUV |
| Certification: |
CE |
| Airflow Direction: |
Cross-flow Type |
| Heating Mode: |
Diesel |
| Paint Mist Treatment: |
Dry-type |
| Condition: |
New |
| Substrate: |
EPS |
| Brand: |
Weilongda |
Product Description
We are professional manufacturer of spray paint booth for over 16 years.
It's a good brand in China even around the world with excellent quality & competitive price.
WLD9000 Luxury Spray Paint Booth (CE)
| External Size | L7000×W5450×H3480(mm) | Air Flow | 25000m³/h |
| Internal Size | L6900×W3900×H2800(mm) | Air Speed | 0.3~0.5m/s |
| Main Door Size | W3000×H2750(mm) | Fuel Consumption | 5~6kg/vehicle |
| Total Power | 15KW | Application | Saloon Car/Jeep/Wooden/Furniture |
| Wallboard | 50mm EPS, foam density is 14kg/m³. 0.476mm colorful steel skin board with hot dip galvanizing, life-span can reach 20 years without rusting. It keeps a high insulation performance with a low weight. |
| Basement | Galvanized steel sheet and square steel pipe construction. 2 rows of grids with floor filter & 3 rows of checkered plates. 3pcs of large ramps. |
| Door | 3 folders of front door, made of 0.8mm colorful steel skin board, with aluminum view window, size: W3000×H2750(mm). 1pc of service door, size: W800×H2000 (mm). |
| Fan | 1×7.5KW direct drive turbo intake fan, 1×5.5KW direct drive turbo exhaust fan. |
| Air Pipe | Made of galvanized steel sheet, consist of 4pcs of straight pipes 750*750*1000 and 1pc of elbow. |
| Primary Filter | Dual filtering structure, the primary filter is M pattern non-woven filter bags. It can capture granules bigger than 10μm. |
| Ceiling Filter | Ceiling filter captures granules larger than 5μm. |
| Floor Filter | Multilayer glass fiber, the air cleanliness in the working environment can reach 98%. Special configure with M pattern active carbon pocket filter system. |
| Burner | Italy Riello RG5S diesel burner, 260000Kcal/h. The heating time is 4~5min (20~60ºC). Max. temperature is 80ºC. |
| Heat Exchanger | Made of stainless steel, two layers and two wings for temperature rising quickly and dissipating more heat, the heat exchange rate can reach 85%. |
| Control Box | Micro-soft computer control box, use high quality electronic component, the temperature and the drying time is accurately shown. Equipped with overheat, overload & short-circuited protected, safe and reliable. |
| Damper | BELIMO 20N electric damper. |
| Ceiling Light | 8 units × 4pcs=32pcs of LED lamps. |
| Side Light | 8 units × 2pcs=16pcs of LED lamps. |
