Wld-a European Standard Car Auto Body Frame Machine

Wld-a European Standard Car Auto Body Frame Machine
Price: US $ 5980-6716/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: T/T
Prod Model: WLD-A
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Working-Bench Length: 5180mm
Working-Bench Width: 2000mm
Working-Bench Height: 320mm
Hydraulic Power: 69MPa
Power Pulling Capacity: 10t
Radius Of Pulling: 360degree
Measuring Accuracy: +-2mm
Air Supply Required: 0.6-0.8MPa
Equipment Overall Weight: 2160kgs
Type: Flatbed-type
Max. Lifting Capacity: 3.5T
Certification: CE
Condition: New

Product Description

WLD-A European Standard Car Auto Body Frame Machine

Factory cost and excellent quality.
Our service tenet is "quality first, service highest".


Technical Parameter:

Working-bench Length5180mm
Working-bench Width2000mm
Working-bench Height320mm
Equipment Overall Weight2160kg
Hydraulic Power0.6-0.8MPa
Measuring Accuracy±2mm
Radius of Pulling360°
Air Supply Required100PSI





Features:

1.  General vehicle body repairing system model WLD-A is a practical and low-price type developed by us.

2. Working bench is welded with steel sheet featured high strength and not easy to deformation.

3. Equipped with the flexible and convenient traveling structure of two drawing towers which enable an easy towers move and fix in a circle along the bench. Oil cylinder vertically mounted enables a strong pulling force without any component force.

4. Movable 3D mechanical measuring system featured a convenient operation and high accuracy.

5. General clamp is applicable on clamping of various cars of home and aboard.

6. Jig and auxiliary of different features can satisfy any repairing operation on distortion in any form.

7. Global-simultaneous car-body database ensure the providing of the lastest and fastest car-body data.
