| Prod Model: |
WLD9000 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| External Size: |
7000*5450*3480mm |
| Internal Size: |
6900*3900*2800mm |
| Main Door Size: |
3000*2750mm |
| Power: |
15kw |
| Air Flow: |
25000m3/H |
| Air Speed: |
0.3-0.5m/S |
| Vehicle Suited: |
Saloon Car/Jeep/SUV |
| Paint Mist Treatment: |
Dry-type |
| Airflow Direction: |
Cross-flow Type |
| Certification: |
CE |
| Condition: |
New |
| Brand: |
Weilongda |
| Heating Mode: |
Gas |
| Substrate: |
EPS |
Product Description
Quick Details
Type: Spray Booths
Power: 15kw
External Size: 7mx5.45mx3.48m
Internal Size: 6.9mx3.9mx2.8m
Voltage: 3 Phase 380V/415V/220V 50Hz/60Hz ect...
Certification: CE
Place of Origin: Guangdong, China (Mainland)
Brand Name: Weilongda
Model Number: WLD9000
Front door: 3 pieces
Emergency door: 1 piece
Packaging & Delivery
Packaging Details: | Polyfoam and carton,1 set in a 20ft container,3 sets in a 40HQ container |
|---|
| Delivery Detail: | 7-10 days after receiving 30% deposit |
|---|
Specifications
1.Big car drying booth factory
2.Italy Riello RG5S diesel burner
3.1 x 7.5kw intake fan, 1x5.5kw exhaust fan
4.Good quality.
Established in 2000,our factory is one of the earliest and largest spray booth and other garage equipment manufacturers in Guangzhou,China.Welcome to visit us.
WLD9000 Car Paint Spraying Baking Booth Configuration:
External Size:(mm) |
7000x5450x3480 |
Front Door:(mm) |
3000(w)x2750(h) |
Internal Size:(mm) |
6900x3900x2800 |
Total Power:(kw) |
14 |
Cabin System |
Wallboard |
Fire-retardant composite molding Sandwich style EPS(epispastics polystyrene)(Rock wool and PU are optional)
50mm thickness, EPS foam Density is 14kg/m³ ;The Colorful steel skin boards have been HDG(hot dip galvanizing),service life can reach 20 years without rusting Thickness is 0.476mm.It keeps high insulation performance with a
low weight. Four colors for your choice,including blue,red,orange and white. High quality galvanized steel roof panel |
Basement |
Galvanized steel sheet and square steel pipe construction.
Full grids,anti-rust and strong, the bearing capacity of driving grids up to 1000 kg; Basement frame is assembly formed by corrosion-resistant steel square tube, the overall performance is good, anti-heavy and strong, not deformed. |
Door |
3 pieces of luxury front doors. Size: 3000(w)*2750(h).
1 piece of emergency door. |
Air Circulation System |
Intake Fan |
1x7.5kw direct drive turbo fan, Air Flow is 25000m3/h. Siemens technology production, large air volume and low noise. |
Exhaust fan |
1x5.5kw direct drive turbo fan, Air Flow is 18000 m3/h,Siemens technology production, large air volume and low noise. |
Air Pipe |
Made of Galvanized steel sheet consisted of 4 pieces of Straight pipe 750*750*1000mm, and 1piece of elbow. |
Air circulation type |
Full inner air circulation type, particularly rapid heating, insulation ability, especially energy, reflect its superior performance in a cold environment. |
Air Flow |
Air Flow: 30000m3/h. Air Speed: 0.3-0.5m/s. |
Heating System |
Burner |
Imported Italy Riello FS20 gas burner, 200000Kcal/h. The heating time 4-5min (20-60°C) Max. Temperature at 80°C. Fuel consumption is 4-5kg/vehicle. |
Heat Exchanger |
Made of stainless steel. The heat exchange rate reaches 85%. |
Air make up cabinet |
The surface plate is galvanized plate, rust force strong, beautiful; The frame is made of high-quality hot-dip galvanized sheet repression,difficult to wear,anti-rust and strong, more durable than ordinary surface treatment, more beautiful, nodes with no damage spot, rigidity. |
Oil tank support |
Tank carefully made of high quality steel, the powder coating treatment, beautiful and durable. |
Fume pipe |
Fume pipe made of galvanized pipe, diameter of 190mm, 4 pieces of 1000mm long straight pipe, two 90 ° elbows. |
Lighting System |
Light tube |
Ceiling light has 32 pieces of 36w lamps. Side light has 16 pieces of 36kw Lamps. 900 Lux. the grade of lighting box's dustproof and waterproof reach IP54 grade. |
Light box |
Medallions of welded galvanized plate, by the spray treatment, stiffness, repeated disassembly easy deformation, surface brightness, color uniformity,
heat is not easy to change color. |
Filtering System
|
Primary filter |
Dual filtering structure. The primary M pattern nonwoven filter bags,it can capture granules larger than 10μm. |
Ceilng filter |
Ceiling filter capture granules bigger than 5μm. The air cleanliness in the working environment can reaches 98%. |
Exhaust filter |
Special configure with M pattern active carbon pocket filter system. |
Ceiling filter support |
made of tube steel frame, thickness of 1.2mm, epoxy powder coating,
anti-rust and strong, rigid, beautiful and durable, can be repeated disassembly, not easy to damage, easy to replace filter cotton. |
Control Panel |
Damper |
Air damper,efficient and durable. |
Contral panel | Use high quality electronic component,the temperature and the drying time is accurately shown,equip with overheat,overload& shortcircuit protected,safe and reliable. Use well-known brand products, reliable quality, stable performance,display accurate. |
