Search and download APP SYTTPMS in Google play or APP store for Android and ios smartphones
1.The pressure / temperature alarm value be adjusted
2.Forget to take Mobile phone ;This system also has the human voice to remind
3.Parking air leakage, open the door immediately remind
4.Tire pressure and temperature units arbitrary switching Global Universal
5.Standard OBD plug and play, apply to most cars with four tires
6.Visual, audible and vibration alarm
OBD Receiver Parameters
1.Rated operating voltage: DC12V
2.Static average operating current: ≤20mA
3.Receiving center frequency: 433.92MHz
4.Receiving sensitivity: ≤-110dBm
5.Bluetooth transmission distance: > 8m
6.Operating temperature range: -40 to 85ºC
7.Pressure alarm upper limit: 40.6Psi to 50.8Psi
8.Pressure alarm lower limit: 21.8Psi to 31.9Psi
Internal Sensor Parameters
*Operating temperature: -40 to 120ºC
*Pressure range: 0 to 65Psi (4.5Bar)
*Pressure accuracy: ±1.5Psi (0.1Bar)
*Temperature accuracy: ±3ºC
*Transmission power: <10dBm
*Transmission frequency: 433.92MHz
*Dimension: 73*63*10mm (Length*Width*Height)
*Battery life: 5 years (Non-replaceable battery)
*Weight: 38 grams
External Sensor Parameters
*Operating temperature: -20 to 80ºC
*Pressure range: 0 to 65Psi (4.5Bar)
*Pressure accuracy: ±1.5Psi (0.1Bar)
*Temperature accuracy: ±3ºC
*Transmission power: <10dBm
*Transmission frequency: 433.92MHz
*Dimension: 20mm*17mm (Diameter*Height)
*Battery life: 2 year
*Battery model: CR1632(Replaceable battery)
*Weight: 10 grams
Q.:How to install External TPMS?
A.: Installation for External TPMS is very simple.Use our tools to install yourself. According to the mark on the sensors Screw on the corresponding tire air nozzle.
Q.: How to install internal TPMS ?
A.:
1. Remove the tire,
2.wear out the sensor from the wheel.replace the original car gas nozzle,and clear it.
3. Tire inflation ,Cover gas nozzle,then do Dynamic balancing machine test
We suggest to let a professional master to install the internal type.
Q:What is the difference between External and internal?
A.:
There are mainly 3difference:
1.installation is different. External can be DIY, simple to install. when the tyre is inflated, the sensor needs to be screwed down. It is a little difficult to set-up, when inflate the tyre no need to remove.
2. Life time is different.External sensor batteries last long for 2years, can be replaced,batteries when power off ,model is CR1632.
Internal sensor batteries can last long for 5years,but could notreplace batteries,need to change a new sensor from us
3. Internal sensor measurement accuracy is higher than the external.
