Water Gas Flow Sensor, Handheld Ultrasonic Flow Meter
| Price: |
US $ 100/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
Hand-held ultrasonic transducer flow meter/portable ultrasonic flow meter
Flow velocity: 0.1 - 12m/s
Accuracy: 0.2
Hand-held ultrasonic transducer flow meter/flow indicator/flow sensor/flow transmitter
/portable ultrasonic flowmeter
Product Description
what's the main features of hand held ultrasonic flow meter ? 1.It's widely used to measure liquid flow in various industries .
2.Many advantages such as smart body, high accuracy, good repeatability,long-running cell,easy operation,built-in printer etc.
3.The flowmeter is very popular in industry like petrochemical, water, power, energy monitoring etc.
4.It's exported to Japan, Korea, Australia, America etc.
what's the main parameters of handheld flow meter ?
1.Accuracy:±1%
2.Repeatability:±0.2%
3.Easy to install outside the pipe
4.line display: Instantaneous flow rate,Accumulate flow,status
5.Standard interface RS232 for data output and on-line operation
6.Self-diagnose to show the current status
7.Built-in Nickel-hydrogen cell supports 10 hours of operation
Data |
S1Z |
M1Z |
S1 |
M1 |
L1 |
S1H |
M1H |
Pipe size |
15-100 |
50-700 |
15-100 |
50-700 |
300-6000 |
15-100 |
50-700 |
Material |
Aluminum Alloy |
ABS |
Special material for hi-temp |
Frequency |
1MHz |
Installation |
V(N,W)flange |
V,Zflange |
V(N,W)flange |
V,Zflange |
Zflange |
V(N,W)Flange |
V,Z flange |
Calibration |
Calibrated together with flowmeter |
Magnetic |
yes |
no |
Temperature |
0°C-70°C |
0°C-160°C |
IP |
IP65 |
Outsize |
200×25×25 |
280×40×40 |
45×30×30 |
60×45×45 |
80×70×55 |
90×85×24 |
90×82×29 |
WT(g/pair) |
250 |
1080 |
75 |
250 |
650 |
94 |
150 |
Medium |
Water,sea water,sewage,Alcohol,oil etc |
Turbidity |
≤10000ppm with little air bubble |
Pipe |
Carbon steel stainless steel,cast iron,Brass,PVC,Aluminum etc. |
Pipe inner |
Rubber,Slurry,PP,PS,bakelite, PTFE |
Signal cable |
standard:5M×2,optinal:10M×2 or 15M×2... |
Optional flow Sensor
S1H Small and High Temperature Resistance type sensor (For N15-100)
Middle and high Temperature resistance type sensor (For DN50-700mm)
S1 series Standard Small-type flow sensor(magnetism)
(For DN15-100mm)
M1 series Standard Mid-type flow sensor(magnetism)
(For DN50-700mm)
L1 series Standard Large-type flow sensor
(For DN300-6000)
Linearity | 0.5% |
| Repeatability | 0.2% |
| Accuracy | ±1% of reading at rates>0.2 mps |
| Response Time | 0-999 seconds, user-configurable |
| Velocity | ±32 m/s |
| Pipe Size | 20mm-6000mm |
| Rate Units | Meter, Feet, Cubic Meter, Liter, Cubic Feet, USA Gallon, Imperial Gallon, Oil Barrel, USA Liquid Barrel, Imperial Liquid Barrel, Million USA Gallons. User configurable. |
| Totalizer | 7-digit totals for net, positive and negative flow respectively |
| Liquid Types | Virtually all liquids |
| Security | Setup values Modification Lockout. Access code needs unlocking |
| Display | 4x8 Chinese characters or 4x16 English letters |
Communication
Interface | RS-232C, baud-rate: from 75 to 57600. Protocol made by the manufacturer and compatible with that of the FUJI ultrasonic flow meter. User protocols can be made on enquiry. |
| Transducers | Model M1 for standard, other 3 models for optional |
Transducer Cord
Length | Standard 2x10 meters, optional 2x 500 meters |
| Power Supply | 3 AAA Ni-H built-in batteries. When fully recharged it will last over 10 hours of operation. 100V-240VAC for the charger |
| Data Logger | Built-in data logger can store over 2000 lines of data |
| Manual Totalizer | 7-digit press-key-to-go totalizer for calibration |
| Housing Material | ABS |
| Case Size | 100x66x20mm |
| Handset Weight | 514g (1.2 lbs) with batteries |
Why choose us ?
1) We are Alibaba Assessed 10 years Gold Supplier.
2) We have about 30 years experience in production.
3) Our products have been exported to more 100 countries and area.
4) 100% QC inspection Before Shippment.
5) ISO,CE,SGS standard and factory price.
| Prod Model: |
TDS-100H |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Accuracy.: |
±0.2-0.5% |
| Medium: |
Liquid |
| Certificate: |
ISO ,SGS and CE |
| Temperature: |
0-160c |
| Measuring Pipe Size: |
Dn50-700mm |
| Output: |
RS485 |
| Display: |
4 Lines Characters LCD Screen |
| Units: |
Gallon, Cubic Feet, Cubic Meter, etc. |
