Name: Water Curtain Spray Paint Booth for Furniture
Brand: ibuyautoparts.com
SKU: 756024955
Availability: InStock
Rating: 4.3 (72 reviews)

Price:	US $ 3500-15000/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Set
Pay Type:	T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	Customized
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model:	Custim-Made
External Size:	700052003000mm
Internal Size:	690039002600
Water Curtain Cabinet Size:	300012001900 2 Sets
Inside Booth Brightness:	800lux
Air Flow:	24000m3/H
Certification:	CE
Airflow Direction:	Fully Undershot-type
Paint Mist Treatment:	Dry-type
Condition:	New
Substrate:	EPS
Brand:	Weilongda

Product Description

1. with over 14 years experience in water curtain spray booth
2. Real baking booth factory in China
3. OEM service, can design according to customers requirement
4. Suitable for Many Kinds of Paint
5. Welcome to visit our factory any time.

Water Curtain Spray Booth

Technical parameter

External size	7000×5200×3000mm
Internal size	6900×3900×2600mm
Water curtain cabinet size	3000×1200×1900mm 2 sets
Inside Booth Brightness	800Lux
Air flow	24000m³/h

Main structure and parts
Consist of cabin, air circulation system and control system

Wallboard: Sandwich style EPS (epispastics polystyrene) 50mm thickness. Galvanized steel roof panel.
Door: 3 pcs of front doors with powder coating treatment frame. Size: 2400(w) x 2600(h). 1 pc of emergency door.
Lighting System: Ceiling light has 24 pcs of 36w lamps. 800 Lux.
Intake Air Circulation System: 2x4kw intake fan. Air Flow 24000 m3/h.
Exhaust Air Circulation System: adopts water curtain filter treatment device. Structure characteristics: Two sets of water curtain painting cabinet in the booth. Water pool adopts 3mm welded steel plate. Air circulation boards adopt 1.5mm thickness steel plate; Water curtain board is stainless steel, each water curtain painting cabinet equips 1 x 3kw pipe type fan for exhausting.1 set of 5.5kw pump for water supply. Water can be recycling use.
Control system: Adopts famous domestic components, Equoip with over load & shortcircuit protected, safe and reliable.
