Vehicle Sideslip Tester /Vehicle Test Line

Name: Vehicle Sideslip Tester /Vehicle Test Line
Brand: ibuyautoparts.com
SKU: 814429455
Availability: InStock
Rating: 4.4 (106 reviews)

Price:	Negotiable/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Max. Axle Load:	3000kg or 10000kg or 15000kg
Measuring Range:	15.0m/Km
Sideslip Board Dimensions:	600500mm,10001000mm,1100*1000mm
Release Board Dimension:	600500mm/1000385mm/1100*385mm
Power Supply:	220V 1phase/380V 3phase 50Hz
Certification:	CE
Update Method:	by Email
Testing Equipment Type:	Test Line

Product Description

Vehicle Sideslip Tester /Vehicle test line

KCH Vehicle Sideslip Tester inspects the matching between wheel camber and wheel toe while the vehicle is driving straightaway. When the vehicle is passing over the Sideslip Plate, the plate is pushed to the left or the right depending on the wheel tracking. Any deviation will be sent to computer by the displacement sensor and appeared in sideslip volume and sideslip direction.

Features:

Sideslip plate & protection frame integrative structure.
Sideslip plate locker with inner key.
No maintenance body design.
Galvanized plate surface for extra long service lift.
High precision sensor to ensure the exactitude of result
upper and lower dual bearing system makes smooth movement
Selection of synchronic or independent motion type for different regulation requirement
Over-load & over-value alarm function
Standard RS-232 connection port

Technical parameters

Model	KCH-3B	KCH-10B	KCH-15B
Max.axle weight	3000kg	10000kg	15000kg
Measuring range	±15.0m/km	±15.0m/km	±15.0m/km
Sideslip board dimensions	*600500mm**	*10001000mm**	*11001000mm**
Release board dimensions	*600500mm**	*1000385mm**	*1100385mm**
Structure form	Single With release Galvanized	Double plates With release board	Double plates With release board
Power supply	AC 220V/380V/50HZ	AC 220V/380V/50HZ	AC 220V/380V/50HZ
