Please note the following specification of SL780:
1.External Locking Rim Dimensions: 300mm-510mm (12″- 20″)
2.Internal Locking Rim Dimensions: 350mm-609mm (14″- 24″)
3.Max Tyre Diameter: 1000 mm ( 39″)
4.Max Tyre Width: 410 mm ( 16″)
5.Bead Breaker Force (10bar) : 2500Kg
6.Working Pressure: 8-10bar(116-145Psi)
7.voltage: 110/220V (1ph) 380V (3ph)
8.Motor Power: 0.75Kw-1.1Kw
9.Technical features:
with oil reserve tank
rapid air inflation
Pneumatic Bead Breaker blade
controlled pressure gage
large tank to invoid rocking bar inclining
10. net weight: 336kgs
gross weight: 397kgs
| Max Tyre Diameter | 1000mm(39") |
| Max Tyre Width | 410mm |
Features:
1. The equipment can be used for different purposes of demounting, mounting and inflating tyres.
2. There is a secondary arm system, increase the coverage of the work, pneumatic control of the manipulator can be free landing lock in any position
3. Pneumatically controlled tilting system saves the effort and time of the operation. Pneumatic lift device can be smoothly and steadily in any position, so that the disassembly of tire more convenient and easy.
4. The steel mount/demount is cast from excellent ,material with special shape and durable performance.
The supplied plastic mount/demount head with the equipment is made from special engineering plastic that has enough intensity and not damage the tyre and rim.
5. The two clamping cylinder ensures accurate central alignment, so that the wheels can be held tightly.
6. Moving up and down of the hexagonal column and locking of the horizontal arm is controlled by a button, which save operation time and make operation safe.
7.Human design of the mount/demount help greatly reduces work-intension of the operator, making tyre-mount and tyre-demount operations convenient and easy.
8.The quick-inflating device keeps tyre bead close to the rim tightly, avoiding over-long time inflation or difficult inflation when the gun inflator is used for the empty tyre.
9.The bead breaker shoe can be adjusted to match tyres with different widths
10.Mount/demount help device and quick-inflating device features simple operation and
reliability. It is a great help in car repair garage and tyre dealers.
