Qingdao Haolida Automotive Equipment Manufacturing Co., Ltd. >> Turbocharger Test Equipment for Truck, Bus, Cars

Turbocharger Test Equipment for Truck, Bus, Cars

Turbocharger Test Equipment for Truck, Bus, Cars
Price: US $ 1/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,Western Union
Prod Model: HLD-QZY-2R
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Name: Turbocharger Test Equipment for Truck,Bus,Cars
Power Source: 380V 50Hz
Power Of Air Generator: 11kw
Certification: ISO
Update Method: by Hard Disk
Testing Equipment Type: Turbocharger Fault Diagnostic

Product Description


HLD-QZY-2R model Turbocharger Test Equipment for truck,bus,cars

General introduction:
This turbocharger test bench is applicable for testing performance of turbocharger on various models truck engines and can carry out dynamic test of boost pressure, air flow and lubrication of turbocharger and display measured data by digital instrument.
It can carry out contrast test of inlet & outlet air pressure difference of various turbochargers and read the values

Advantages:

1.It is with indicator lamp following each step and warn you the problems.
2.It possesses high control sensitivity and strong controllability.
3.It is easy to learn and operate.
4.It has a protective cover to avoid danger during test
5.It can test various kinds of turbochargers as long as they are with the same working principle
6.It is matched with PLC computer to operate, display, save & print test results and curves.
7.It adopts electrical heating to make high temperature test of the turbocharger, simulating the running state on the cars, the speed can reach hundred thousands r/min.
8.It uses high precision sensor,simulating the working state of the turbocharger on the vehicle

Test items:

1.Test speed of turbocharger
2.Test air flow of turbocharger
3.Test boost pressure of turbocharger
4.Test lubrication state of turbocharger
5.Test turbine inlet temperature of the turbocharger
6.Test turbine outlet temperature of the turbocharger
7.Test the temperature of the lubrication oil
8.Test the inlet pressure of the turbocharger



Technical parameter:


Model no
HLD-QZY-2R
LanguageEnglish
MaterialMetal plate
PaintingPowder painting, durable and beautiful
ColorBlue
Voltage380V 50 Hz 3P
Power of air generator11KW
Frequency converter power15KW
Input air source1.0Mpa
Motor power of the oil pump370W
Rated pressure of the oil pump0-2.0Mpa(adjustable)
Maximum displacement of oil pump6L/min
Speed of the turbocharger0-100000r/min
Power of the heater57KW   0-500ºC adjsutable
Accessories:
Accessory wires, clamps, etc.
Others you may want to know:
MOQ1set
Warranty period12 months
Payment termT/T 50% in advance, the balance should be paid before delivery  (negotiable)
Delivery time35 days after receiving downpayment
HS code90312000.90
PackingExport plywood case
