| Prod Model: |
K03 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Part Number: |
53039700003, 53039880003 |
| OE Number: |
028145701r |
| Chra: |
53037100500 |
| Engine: |
Aaz |
| Displacement: |
1.9L, 1896 CCM, 4 Cylinders |
| Kw: |
55/75 HP |
| Turbine Wheel: |
53031205016 |
| Comp. Wheel: |
53031232011 |
| Heat Shield Number: |
5303165-2000 |
| Repair Kit: |
53037110001 |
| Certification: |
CE |
Product Description
Turbocharger Kkk K03 Turbocharger 53039880003 028145701R
| Part Number | 53039880003 |
| Previous Version | 5303-988-0003, 5303 988 0003 |
| OE number | 028145701R |
| Year | 1993-09 |
| Description | Commercial Golf III, Vento TD, Passat III TD, Ibiza, Cordoba TD, Toledo TD, Audi A4, 80 TD |
| Manufacturer Part Number | 53039700003 |
| CHRA | 53037100500 |
| Turbo Model | K03-1870EAA3.81KCAAD |
| Engine | AAZ, 1.9L 'Umwelt-Diesel' |
| Displacement | 1.9L, 1896 ccm, 4 Cylinders |
| KW | 55/75 HP |
| RPM Max | 4400 |
| Fuel | Diesel |
| Angle α (compressor housing) | 337.5 |
| Angle β (turbine housing) | 45 |
| Bearing Housing | 53041510003/53041500011/53041500014 $61.60 |
| Turbine Wheel | 53031205001/53031205016/53031205016 |
| Comp. Wheel | 53031232011 |
| Back plate | 53031515701/53031515700 |
| Heat shield Number | 53031652000 |
| Repair Kit | 53037110001 |
| Turbine Housing | 53031009004 |
| Compressor Cover | 53031015009 |
| Turbine Housing AR | 3 |
| Actuator | 58201104500 |
| Settings waste gate (pressure) | 1.000 bar |
| Settings Waste gate (lift shaft) | 3.70 mm |
| Gasket (turbine inlet) | 210292 |
| Gasket (turbine outlet) | 210296 |
| Gasket (turbine inlet) | 210317 |
Applications
95-98 Volkswagen Commercial Vento with AAZ Engine
93-09 Volkswagen Golf III, Passat III TD, Vento TD with AAZ Engine
94-03 Audi 80 TD with AAZ Engine
96-03 Audi A4 with AAZ Engine
93-09 Seat Cordoba TD, Ibiza, Toledo TD with AAZ Engine
