Name: Truck Mounted Garden Water Hose Reel
Brand: ibuyautoparts.com
SKU: 768523215
Availability: InStock
Rating: 4.4 (48 reviews)

Price:	US $ 255-300/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Features of reel
Series 420 reels, in terms of research and design, selection of materials,
or manufacturing everywhere focus on its characteristics and special
requirements of automotive applications, thickening of the plate, rugged
construction, making it shock resistance, stability and taste, storage space
large, can be wound larger size, longer hose length range of applications to
be fully extended.
Fluid path:1/4 ", 5/16", 3/8 ", 1/2", 3/4 ", 1"

The Specifications:

Appilication	Pressure Mpa(psi)	Hose inner dia. mm (In)	Hose length m (ft)	Reel inlet	Reek outlet	Pin No. (with hose)	Pin No. (without hose)
Air/Water/Anti-freeze	2(300)	6 (1/4)	120(393)	M14×1.5	M14×1.5	-	420020100
Air/Water/Anti-freeze	2(300)	8 (5/16)	120(393)	M18×1.5	M18×1.5	-	420020200
Air/Water/Anti-freeze	2(300)	10(3/8)	100(328)	M18×1.5	M18×1.5	-	420020300
Air/Water/Anti-freeze	2(300)	12(1/2)	80(262)	M22×1.5	M22×1.5	-	420020400
Air/Water/Anti-freeze	2(300)	19(3/4)	50(164)	M30×1.5	M30×1.5	-	420020600
Air/Water/Anti-freeze	2(300)	25(1)	30(100)	M36×2	M36×2		420020700
Oil/Water	19(2780)	6 (1/4)	120(393)	M14×1.5	M14×1.5	-	420190100
Oil/Water	15(2280)	10(3/8)	100(328)	M18×1.5	M18×1.5	-	420150300
Oil/Water	14(2030)	12(1/2)	80(262)	M22×1.5	M22×1.5	-	420140400
Oil/Water	8(1160)	19(3/4)	50(164)	M30×1.5	M30×1.5	-	420080600
Air/Water/Anti-freeze	2(300)	6 (1/4)	120(393)	M14×1.5	M14×1.5	-	EM420020100
Air/Water/Anti-freeze	2(300)	8 (5/16)	120(393)	M18×1.5	M18×1.5	-	EM420020200
Air/Water/Anti-freeze	2(300)	10(3/8)	100(328)	M18×1.5	M18×1.5	-	EM420020300
Air/Water/Anti-freeze	2(300)	12(1/2)	80(262)	M22×1.5	M22×1.5	-	EM420020400
Air/Water/Anti-freeze	2(300)	19(3/4)	50(164)	M30×1.5	M30×1.5	-	EM420020600
Air/Water/Anti-freeze	2(300)	25(1)	30(100)	M36×2	M36×2		EM420020700
Oil/Water	19(2780)	6 (1/4)	120(393)	M14×1.5	M14×1.5	-	EM420190100
Oil/Water	15(2280)	10(3/8)	100(328)	M18×1.5	M18×1.5	-	EM420150300
Oil/Water	14(2030)	12(1/2)	80(262)	M22×1.5	M22×1.5	-	EM420140400
Oil/Water	8(1160)	19(3/4)	50(164)	M30×1.5	M30×1.5	-	EM420080600

Prod Model:	Series 420
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Drive Type:	Spring
Spring Brand:	Kern-Liebers
Construction:	All Bolted Unitized
Mounting:	Floor, Wall, Bench, Truck
Inlets:	1/4", 5/16", 3/8", 1/2",3/4",1"
Material:	3.0mm Cold Steel
Surface Finish:	Powder Coated
Color:	Red
